LL REGISTER ADDRESSES
104 Status bits
outputs
45.1 105 Valve position set-
point active with
extra frost protection
140 Unit temperature,
sensor X360
141 Discharge tempera-
ture, sensor X350
142 Error bits from unit
144 Status bits
inputs
145 Temperature sensor
X540
For SR and
IndAC
temperature
For NOZ
temperature
146 Input voltage, ana-
logue input X375
en-20
Bit
%
0.1°C
0.1°C
Bit
Bit
0.1°C
: Outdoor
2
: Room
2
0.01 V
0 6
0 100
0 15
0 6
M / BAC
ODBUS NET
0 (+1) = output 1 ro
1 (+2) = output 2
2 (+4) = cooling
3 (+8) = heating
4 (+16) = on
5 (+32) = room con-
trol active (menu
parameter 45.1 (105)
is not active)
6 (+64) = output 3
ro
ro
ro
ro
0 (+1) = ok (not ro
used)
1 (+2) = err (not
used)
2 (+4) = status config.
button
3 (+8) = input 1
4 (+16) = input 2
5 (+32) = PIR input
6 (+64) = input 3
ro
ro
L
G
L
L
L
L
L
L
