1- After laying out all components, position the Seat ( B ) upside-down and align the Back Leg Assembly ( C ) with
the Seat Supports, as shown below. Insert a Screw ( A ) through a Seat Support into a predrilled hole and begin to
tighten the screw with a screwdriver. Once the screw is a few turns tightened, move on to another screw until all 4
have been started. With the Seat loosely attached to the Front Leg, use an additional Screw ( A ) to attach the Leg
Support to the Seat. With this 5th screw tight, finish tightening the first 4 screws into the Legs.
A
Hardware and Parts
1.50
2.50
( Front Leg
Do not use
any hand drill
on this product
Figure 1
Assembly Instructions
Hudson 17" Bar Height Stool
B
( Seat )
D
Assembly )
( Back Leg Assembly )
C
Leg
Support
Seat
Support
Item No: MHUD-S17B
C
( Back Leg
E
( Stretcher )
Assembly )
