LaMotte STORMWATCH MS4 Manual

Water screening kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
STORMWATCH
WATER SCREENING KIT
MS4
Code 7449

Advertisement

Table of Contents
loading

Related Manuals for LaMotte STORMWATCH MS4

Summary of Contents for LaMotte STORMWATCH MS4

  • Page 1 STORMWATCH WATER SCREENING KIT Code 7449...
  • Page 2 WATER SCREENING TEST PROTOCOLS FOR STORMWATER MS4 GUIDANCE USING COLORIMETRIC AND TURBIDIMETRIC TECHNIQUES  OVERVIEW According the U.S. Census bureau the world’s population went from 2.5 billion in 1950 to 6 billion in 2000 and is on pace to exceed 9 billion by 2050. We will soon have 3 times the global population we had only in 1950, and with this growth comes enormous impacts on the surface of our globe.

  • Page 3: Making Measurements

    EXAMPLES OF OUTFLOWS Outfl ows attributable to a rainwater event can occur across a number of different environments. These include: • Agricultural runoff • Industrial sites • Construction sites • Irrigation runoff • Parking lots and pavement • Other While illicit discharges of various chemical constituents into stormwater drains represent a portion of the overall problem, these are not normally defi...
  • Page 4 titrant. The titration endpoint is identifi ed by the development of color resulting from the reaction with an indicator, by the change of electrical potential or by the change of pH value. Ion Selective Electrode An ISE is a transducer (or sensor) that converts the activity of a specifi c ion dissolved in a solution into an electrical potential, which can be measured by a voltmeter or pH meter.
  • Page 5 applicable in communities where hardness levels are elevated in groundwater due to karst or limestone terrain. In these regions, hardness can help distinguish natural groundwater fl ows present in outfalls from tap water and other fl ow types. Most discharge fl ow types are neutral, having a pH value around 7, although groundwater concentrations can be somewhat variable.
  • Page 6 Test Factor Methodology Action Level Ammonia Ammonia forms a colored complex with Nessler’s ≥50 mg/L Nitrogen Reagent in proportion to the amount of ammonia present in the sample. Rochelle salt is added to prevent precipitation of calcium or magnesium in undistilled samples.
  • Page 7 *WARNING: Reagents marked with an * are considered to be potential health hazards. To view or print a Safety Data Sheet (SDS) for these reagents go to www.lamotte.com. Search for the four digit reagent code number listed on the reagent label, in the contents list or in the test procedures.
  • Page 8 7. Remove tube from colorimeter. Add 8 drops of Ammonia Nitrogen Reagent #1 (V-4797). Cap and mix. Wait 1 minute. 8. Use the 1.0 mL pipet (0354) to add 1.0 mL of *Ammonia Nitrogen Reagent #2 (V-4798). Cap and mix. Allow 5 minutes for maximum color development.
  • Page 9 COLOR • SMART3 COLORIMETER Platinum Cobalt Method • No Reagents Required RANGE: 0–1000 color units MDL: 20 Cu METHOD: Color is determined by a meter that has been calibrated with colored standards of known platinum cobalt concentration. True color, the color of water in which the turbidity has been removed, is measured.
  • Page 10 *WARNING: Reagents marked with an * are considered to be potential health hazards. To view or print a Safety Data Sheet (SDS) for these reagents go to www.lamotte.com. Search for the four digit reagent code number listed on the reagent label, in the contents list or in the test procedures.
  • Page 11 8. Use the 0.05 g spoon (0696) to add one measure of *Tetraphenylboron Powder (6364). Cap and shake vigorously for 20 seconds until all of the powder has dissolved. Wait 5 minutes. 9. At end of 5 minute waiting period, mix tube again to suspend any settled precipitate.
  • Page 12 TURBIDITY • SMART3 COLORIMETER Absorption Method • No Reagents Required RANGE: 0–500 FAU (Formazin Attenuation Units) MDL: 3 FAU METHOD: Absorptimetric, 180° detector SAMPLE HANDLING & Measure sample as soon as possible after collection. PRESERVATION: INTERFERENCES: Check for stray light interference. PROCEDURE 1.
  • Page 13 *WARNING: Reagents marked with an * are considered to be potential health hazards. To view or print a Safety Data Sheet (SDS) for these reagents go to www.lamotte.com. Search for the four digit reagent code number listed on the reagent label, in the contents list or in the test procedures.
  • Page 14 6. If the plunger tip reaches the bottom line on the Titrator scale (200 ppm) before the color change occurs, refi ll the Titrator and continue the titration. When recording the test result, be sure to include the value of the original amount of reagent dispensed (200 ppm).
  • Page 15 CONDUCTIVITY • TRACER For complete instructions, see the Tracer manual. Before fi rst use, hold the meter by the top battery compartment and swiftly tap the back of the meter downward into your palm (not a hard surface). This assures that the internal electrolyte moves to the very tip of the electrode. The electrolyte should fi...
  • Page 16 MEASUREMENT 1. For small samples fi ll a sample cup to the 20 mL line with the test sample. Sample depth must be greater than or equal to 1.5 inches. 2. Press the ON/OFF button. (8888 and then SELF CAL will appear in the display during the initial diagnostics).
  • Page 17 pH • TRACER For complete instructions, see the Tracer manual. Before fi rst use, hold the meter by the top battery compartment and swiftly tap the back of the meter downward into your palm (not a hard surface). This assures that the internal electrolyte moves to the very tip of the electrode. The electrolyte should fi...
  • Page 18 5. The appropriately circled indicator (L, M or H) will appear on the display when a calibration has been completed within one power on cycle. 6. For a two or three point calibration, repeat steps 1-5 with the remaining buffers. 7.

  • Page 19: Epa Compliance

    The instrument has earned the European CE Mark of Compliance for electromagnetic compatibility and safety. The Declaration of Conformity for the instrument is available at www.lamotte.com. This device complies with Part 15 of the FCC rules. Operation is subject to the...

  • Page 20: The Display & The Menus

    SMART3 GENERAL OPERATING PROCEDURES THE KEYPAD The keypad has 6 buttons which are used to perform specifi c tasks. This button will scroll up through a list of menu selections. The button is used to select choices in a menu viewed in ENTER the display.

  • Page 21: Setting The Clock

    PC LINK The meter may be interfaced with any Windows-based 64 bit computer by using the LaMotte WaterLink Connect program and a USB cable. The program will store test information and results in a local database, and allow for exporting this data to a comma separated value (CSV) fi le. The meter will send the following data: time/date stamp, name of test, sample value, sample units, meter name, and location.

  • Page 22: Setting The Data Logger

    SETTING THE DATA LOGGER NOTE: Data from the data logger must be retrieved in the same language in which it was collected. The default setting for the data logger is enabled. The meter will log the last 500 data points. The counter in the center bottom of the display will show how many data points have been logged.

  • Page 23: Setting The Backlight Time

    SETTING THE BACKLIGHT TIME The backlight illuminates the display for enhanced viewing. The default setting is 10 seconds. If Button Control is chosen the backlight button on the key pad will act as an on/off switch and the backlight will remain on or off when the meter is being used.

  • Page 24: Battery Operation

     BATTERY BATTERY OPERATION The meter may be operated on battery power using a USB wall adapter or USB computer connection. If using the meter as a bench top unit, use the wall adapter if possible to extend the battery life. The meter will remain on when the USB adapter is used.

  • Page 25: Battery Replacement

    Handle the tubes carefully, making sure the bottom half of the tube is not handled. LaMotte Company makes every effort to provide high quality colorimeter tubes. However, wall thicknesses and diameter of tubes may still vary slightly. This may lead to slight variations in results (e.g. if a tube is turned while in the sample chamber, the reading will likely change slightly).

  • Page 26: Meter Disposal

     METER DISPOSAL Waste Electrical and Electronic Equipment (WEEE) Natural resources were used in the production of this equipment. This equipment may contain materials that are hazardous to health and the environment. To avoid harm to the environment and natural resources, the use of appropriate take-back systems is recommended.
  • Page 27 container and mix. Transfer back 10 mL of the diluted sample to the tube and follow the test procedure. Continue diluting and testing until a reading, which is in the concentration range for the test, is obtained. Be sure to multiply the concentration found by the dilution factor (the number of total 10 mL volumes used).
  • Page 28 DIRECT READING TITRATOR The Direct Reading Titrator consists of a plastic barrel, a plastic plunger, and a plastic adapter tip. Plunger Barrel Adapter tip The adapter tip reduces the size of the drops that are dispensed and increases the precision of the test results. DO NOT REMOVE THE ADAPTER TIP . INSTRUCTIONS These are general instructions for the use of the Direct Reading Titrator.
  • Page 29 4. Depress the plunger of the Titrator. 5. Insert the adapter tip into the special plastic plug in the titration solution bottle. 6. Invert the bottle. Hold the bottle and the Titrator fi rmly together. Slowly pull out the plunger until the large ring on the plunger is opposite the zero (0) line on the scale.
  • Page 30 9. Turn the bottle right side up and remove the Titrator. 10. Insert the adapter tip into the opening of the tiration tube cap. Slowly depress the plunger to dispanse the titrating solution. Gently swirl the tube to mix the solution. 11.
  • Page 31 KIT CONTENTS Quantity Contents Code 30 mL Ammonia Nitrogen Reagent #1 V-4797-G 2 x 30 mL Ammonia Nitrogen Reagent #2 V-4798-G 30 mL Sodium Hydroxide, 1.0N 4004WT-G Tetraphenolboron Powder 6364-C 15 mL Hardness Reagent #5 4483-E Hardness Reagent #6 Tablets 4484A-H 60 mL Hardness Reagent #7...
  • Page 32 PO Box 329 • Chestertown • MD • 21620 • USA 800-344-3100 • f 410-778-6394 • www.lamotte.com 7449-MN-01 • 10/19...
