# DESCRIPTION
RETAINING RING 3/16" EXTERNAL
1
STAINLESS
CALIBRATION SCREW
2
7/32" ACETAL BALL
3
CONTROL SPRING MASTER
4
1500/2000/4000
8-32 X 1" BUTTON HEAD SCREW
5
3/16" TORLON BALL
6
STO DETENT SPRING
7
ADJUSTING KNOB
8
CAP - SELECTABLE & FIXED
9
10 O-RING-235
1/8 X 5/8 HDP SPIROL PIN
11
12 CAP
13 FLUSH SEAL
14 O-RING-021
15 POPPET
16 RETURN SPRING
17 BAFFLE
18 O-RING-119
19 SHAPER
20 NYLON BUSHING 1/4" LONG
21 CAM SCREW
22 O-RING-348
23 WEAR STRIP
24 BARREL CONE
25 O-RING-237
26 O-RING-014
27 O-RING-006
28 CONTROL ROD - 1250
CONTROL ROD - 1000
29 ROD SPRING - MASTER 1250
30 SHAFT - 1250
SHAFT - 1000
31 BARREL
32 QUAD-RING-239
33 STREAM STRAIGHTENER
34 LOCKING SLEEVE
35 SHAFT LOCK NUT
36 O-RING-243
37 NYLON BUSHING 3/8" LONG
38 SELECTOR RING
39 SELECTOR RING SCREW
40 SELECTOR INNER RING
41 KEY
42 ROD LOCK NUT
43 NOSE CONE TIP
44 NOSE CONE
45 BASE RING
46 3/16" SS BALL
47 COUPLING 2.5"NHF RL
48 1/4-28 X 1/2 SOCKET SET SCREW
49 GASKET 2.5"
* Consult Factory for special threads
QTY. PART #
2 M539
1 M566
2 V2130
1 MS760
2 VT08-32BH1.0
2 V2120-TORLON
2 VM4200
1 M536
1 M534
1 VO-235
2 VP125X625H
1 M535
1 M525
1 VO-021
1 M540
1 MM770
1 M530
1 VO-119
1 M503
2 M556
6 FF126
1 VO-348
1 MM210
1 M501
2 VO-237
1 VO-014
4 VO-006
1 M572
1 M572A
1 M557
1 M575
1 M575A
1 M507
2 VOQ-4239
1 M505
1 MM271
1 M560
1 VO-243
2 AY307
1 M550
2 M561
1 M555
2 M559
2 M585
1 M577
1 M576
1 M500
48 V2120
1 M307*
1 VT25-28SS500
1 V3190
12
LIM-045 September 15, 2015 Rev00
