- Page 1 Liquid Dosing Set ES-FLOW™/GEMÜ 650 Quick Installation Guide Doc. no.: 9.17.148 rev. A Date: 15-10-2020...
- Page 2 Introduction Intended use The ES-FLOW™/GEMÜ 650 Liquid Dosing Set has been developed to accurately measure and control volume flow rates in a fluid system, using the media and operating conditions (e.g. temperature, pressure) as specified at ordering time. Any other use than mentioned here is considered unintended.
- Page 3 *) Not included in scope of delivery This representation shows the ES-FLOW™ from the rear and assumes that the process liquid flows from right to left through the flow controller and the control valve. Depending on the ordered configuration of the ES-FLOW™, the normal flow direction may differ from this assumption, which affects the way in which the components are to be connected in step 2a.
- Page 4 · Preferably install the ES-FLOW™ in a horizontal pipe segment or a segment where the flow direction is upward. · Where applicable, use the provided mounting holes to fixate the equipment. Consult the according dimensional drawing(s) for the exact sizes and locations of the mounting points.
