7.0 TROUBLE-SHOOTING

SYMPTOM
PRO/pak will not make foam
Foam is Intermittent
Poor Quality Foam

8.0 CLEAN UP AND MAINTENANCE

Turn the percentage knob to the OFF position. Use the hose, or hose and
straight stream nozzle, to rinse off the PRO/pak. Reset percentage knob to
proper percentage when finished.
For years of service, periodically inspect your PRO/pak. Make sure the hose
and three nozzles are in place. Look for debris in the bottom of the tank and
flush if necessary.
8.1 DRAIN HOLE
If the PRO/pak is often used for different foam concentrates, it may be helpful
to install a drain to aid in emptying the tank. Drill and tap the left front ear of the
tank and install a ¼" NPT Pipe plug. Plastic or Brass preferred.

9.0 SPECIFICATIONS

Tank Capacity (to bottom of fill port)
Nominal flow (all nozzles)
Weight Empty
Weight Full
Length x Width x Height
Operating Pressure Max/Min
Straight Stream Nozzle Reach
Low Expansion Nozzle Reach
POSSIBLE CAUSE
Out Of Foam
Percentage Knob is OFF
Percentage Knob is plugged
Non-standard outlet hose being used which
is too long or too small in diameter
Foam tank is nearly empty
PRO/pak tilted
Air vents are plugged
Debris in nozzle
Debris under knob
Foam solution velocity too high
Foam gets thick when cold
U.S. Units
2.5 U.S. gallons
12 gpm at 100 psi
11.5 lb
30.1 lb
13.5 x 10.75 x 17 in
500/40 psi
50 feet at 100 psi
37 feet at 100 psi
REMEDY
Refill Tank
Select desired percentage
Remove screw on Percentage Knob,
inspect and clean holes in top of control
block and foam passages in bottom of
Percentage Knob
Order long hose option TFT part U-HS6 or
U-HS25
Refill tank
Keep Twist Grip Horizontal
Make sure that the small black rubber
valve on the inside of the foam tank lid is
not stuck down with dried foam
concentrate
Inspect nozzle, look for plugged holes
Unscrew Knob, inspect and clean
Partially close Flow Control
Select Another Foam
DRILL 7/16" HOLE
TAP ¼" NPT
LEFT FRONT ONLY!
Metric Units
9.5 liters
45 l/min at 6.8 bar
5.2 kg
13.6 kg
345 x 275 x 430 mm
40/3 bar
15 meters at 6.8 bar
11 meters at 6.8 bar
