6.0 TROUBLE-SHOOTING

SYMPTOM
DECON/pak will Out Of Agent
not make agent
Percentage Knob is in RINSE
Percentage Knob is plugged
Non-standard outlet hose being used which is too long or
too small in diameter
Agent tank is nearly empty
Agent is DECON/pak tilted
Intermittent
Air vents are plugged
Poor Quality Debris in nozzle
Agent
Debris under knob
Agent solution velocity too high
Agent gets thick when cold

7.0 CLEAN UP AND MAINTENANCE

Turn the percentage knob to the RINSE position. Use the hose, or
hose and nozzle, to rinse off the DECON/pak. Reset percentage
knob to proper percentage when finished.
For years of service, periodically inspect your DECON/pak. Make
sure the hose and fan nozzle are in place. Look for debris in the
bottom of the tank and flush if necessary.

7.1 DRAIN HOLE

If the DECON/pak is often used for different agent concentrates,
it may be helpful to install a drain to aid in emptying the tank. Drill
and tap the left front ear of the tank and install a ¼" NPT Pipe
plug. Plastic or Brass preferred.

8.0 SPECIFICATIONS

Tank Capacity (to bottom of fill port)
Nominal flow (all nozzles)
Weight Empty
Weight Full
Length x Width x Height
Operating Pressure Max/Min
©Copyright Task Force Tips, Inc. 2017
POSSIBLE CAUSE
9
Refill Tank
Select desired percentage
Remove screw on Percentage Knob, inspect and clean
holes in top of control block and agent passages in
bottom of Percentage Knob
Order other hose option TFT part U-HS, U-HS6 or
U-HS25
Refill tank
Keep Twist Grip Horizontal
Make sure that the small black rubber valve on the
inside of the agent tank lid is not stuck down with dried
agent concentrate
Inspect nozzle, look for plugged holes
Unscrew Knob, inspect and clean
Partially close Flow Control
Select Another Agent
DRILL 7/16" HOLE
TAP 1/4" NPT
LEFT FRONT ONLY!
U.S. Units
2.5 U.S. gallons
12 gpm at 100 psi 45 l/min at 6.8 bar
11.5 lb
30.1 lb
13.5 x 10.75 x 17 in 345 x 275 x 430 mm
500/40 psi
REMEDY
Metric Units
9.5 liters
5.2 kg
13.6 kg
34.5/3 bar
