Transport/storage/packaging

Transport weight
Checking the transport
Working materials
Opening the transport unit
Transport to the
installation site
9229 0106 176 0-
2020-09-18

Transport

Refer to the delivery documents for the weight of the transport unit.
Note
Observe stacking height
For transport, no more identical transport units may be stacked on top of each
other than indicated on the transport unit.
Observe loads specified on the transport unit.
Note
Secure load
For transport, secure the load in such a way that the transport unit is not at risk.
After receipt of delivery:
• Check the transport unit for damage.
unit • Major damage must be documented photographically.
• Ensure that any damage to the transport unit is confirmed by the transport com-
pany in writing.

Scope of delivery

Delivery includes:
• 3TM vacuum contactor
• Operating instructions
• Connector (accessory pack)

Unpacking

Required tools: Knife/scissors.
• Place the transport unit on a level, non-slip and pressure-resistant surface.
• Open the box.
• Check that the delivery is complete.
• Check the vacuum contactor for damage.
Note
Do not use the vacuum contactor if parts are broken, i.e. if you find cracks, flaking,
bent metal parts, damaged plug-in contacts, tears, or bare cables.
Send it back in its original transport unit (see "Reuse of transport unit", page 10).
Note
Transporting the vacuum contactor
Transporting the vacuum contactor by holding and lifting the auxiliary switches on
the sides (23) leads to material damage.
Only transport the vacuum contactor by holding it under the operating mechanism
box (34), the base plate (2), or the pole shells (7).
Remove the supplementary equipment and store safely in the packaging for later in-
stallation.
