Summary of Contents for ECO-WORTHY 3000W
-
Page 2: Specification
4.Intelligent LCD display function, which can display the working parameter information of the inverter in real time like : battery charging mode,solar voltage input,grid voltage input,output voltage, total power consumption... Specification Rated output wattage(W) 3000W Rated pv input voltage(Vdc) Rated output voltage（Vac） 110Vac Maximum pv input wattage(Vdc) 2000W... -
Page 3: Product Detail
Product detail About Wiring Solar panel wiring When using solar panels to charge the battery, Solar panels with a maximum input voltage of 18V need to be connected in series. The wiring method is as follows... -
Page 4: Battery Connection
Solar panels with a maximum input voltage of 36V. When multiple solar panels are needed, please connect them in parallel Battery connection Calculation method for battery selection Since the inverter needs a relatively large working current when working at full load, if the capacity of the battery is insufficient and the maximum output current is insufficient, it will cause the battery to be deeply discharged in a short time and cause damage to the battery.Therefore, the scientific and reasonable choice of the battery is to increase the inverter... - Page 5 Choose a suitable battery Since the inverter requires a relatively large working current when working at full load, if the capacity of the battery is insufficient and the maximum output current is insufficient, the battery will be deeply discharged for a short time and cause damage to the battery Therefore, the scientific and reasonable selection of batteries is a guarantee to improve the service life of inverters and batteries Calculation formula for battery model selection...
- Page 6 Electric power first mode: when the mains power is available, the mains power is given priority to the load.When the mains power is abnormal, it will automatically switch to photovoltaic power supply. Power supply to the load (in this mode, the AC charger starts and will continue to charge the battery) Electric power first mode Battery power first mode...
-
Page 7: Electrical Cable Connection
Electrical cable connection It is necessary to confirm that the inverter switch is in a safe disconnection state, and the equipment is properly placed before connecting the cables. Do not reverse the battery's positive and negative poles, this may cause damage to the inverter The inverter electrical cables must be connected in the following order: 1.Turn off the inverter switch 2.Connect the battery terminal to the battery positive and negative... - Page 8 3.Turn on the inverter switch, start the inverter 4.Connect the load to the AC output socket on the output side panel of the inverter Note that the car cigarette lighter is only allowed to output 150 watts of power, and exceeding the power may affect the safety of use...
-
Page 9: Recommended Environment
Recommended environment The installation and use environment of the inverter should be well ventilated, away from water sources, heat sources, and flammable and explosive materials.Avoid installing the inverter in an environment with direct sunlight, dust, volatile gases, corrosive substances, and excessive salt Note The operating temperature range of the inverter is -10 ~ 40. - Page 10 5. The machine should be placed indoors. In a well-ventilated place, the device should not be covered by other objects, and there should be no flammable or explosive products nearby 6. It is strictly forbidden to connect to the input end of the device Warning Read and ensure that you understand all the contents of this manual.
