TVB-1 Technical Specifications

MODEL
COMPONENTS
120KΩ
2MΩ
GENERAL
TEST POINTS
PASS
ACW / DCW 2MΩ / 6W
FAIL
ACW / DCW 120kΩ / 50W
ENVIRONMENT
DIMENSION
WEIGHT
Symbol Explanation:
Please refer to the instruction manual for specific warning or caution information to avoid personal injury or damage to the
product.
S'il vous plaît se référer au manuel d'instructions de mise en garde ou
ou des dommages au produit
To indicate hazardous voltages may be present.
Avertissement des tensions dangereuses qui peuvent être présentes
© Ikonix USA
TEST CONDITION
1. ACW: 1240V, 10mA or DCW: 2121V, 5000uA
2. Maximum Voltage 2500V
3. Test duty cycle, OFF time = ON time x 2
4. Maximum ON time limit 30 seconds
5. Recommended 2s ramp time
1. ACW: 1240V, 10mA or DCW: 2121V, 5000uA
2. Maximum Voltage 2300V
3. Test duty cycle, OFF time = ON time x 8
4. Maximum ON time limit 5 seconds
5. Recommended 2s ramp time
32° F - 104° F (0° - 40° C)
7.3" (W) x 5.75" (L) x 2.95" (H) , 186mm x 146mm x 75 mm
0.70 Kg, 1.55 lbs.
-1
TVB
RESISTOR SPECIFICATION
2.5 KVAC / 50W / 1% +/- 50ppm
3K VDC / 3W / 1% +/- 50ppm
2% of resistor value
2% of resistor value
information sur la prudence pour éviter des blessures
TVB-1 Instruction Sheet
SPECIFICATION
