Putting into Service

• Carefully remove the transport protection and the packaging.
• Keep the packaging material and small parts out of the reach of children to prevent swallowing or choking.
• The product is delivered folded. Note the remarks for folding found in the section on adjustment options.
Using the release lever, the seat can be removed from the A-Chassis Advantage without tools. It is important that the re-
lease lever remains actuated while inserting and removing the seat unit. No tools are required when using the seat unit
and the chassis for the first time, except for the Allen wrench that is included in the scope of delivery.

Teaching the User

The user is taught how to use this device by trained staff who will reference these Instructions for Use.

Adjustment Options / Features

The settings / adjustments must always be made by trained / instructed professionals (such as medical product consult-
ants of specialist medical dealers).
Seat unit
Inserting the seat unit
Activate the release lever on the headrest tubes and insert the seat unit into the chassis from above (Fig. 7). Make sure
that the buttons on the sides of the seat unit between the folding joint and the connecting strap of the rear frame and
the sliding support are properly threaded through (Fig. 8). Now guide the buttons on the sides of the seat unit into the
receiving slots on the sides of the chassis (Fig. 9) and let the seat unit slide into position (Fig. 6). When you release the
trigger, the seat unit engages into the closest position of the hole matrix.
Caution: Always ensure that the locking pins on both sides of the seat unit engage firmly into a hole in the hole matrix.
Removing the seat unit
To remove the seat unit, actuate the release lever and pull the seat unit upwards out of the frame (Fig. 7). Make sure that
the buttons on the sides of the seat unit between the folding joint and the connecting strap of the rear frame and the
sliding support are properly threaded through (Fig. 8).
Attaching the footrest
The footrest must be fastened to the knee joints. To do this, align the ratchet joints and fasten them to the screws (from
the inside), the saddles (from the outside) and the eccentric levers (from the outside; Fig. 11).
Upholstery
Seat cushion
The seat cushion consists of two elements: the main gray cushion as well as a black additional pad for more comfort.
The additional pad is attached with hook and loop fastener to the underside of the main cushion (Fig. 12). In this regard,
pay attention that the notch in the additional pad is facing forward (Fig. 13). Fasten the seat cover by firmly attaching it
to the rear end of the seat plate using the hook and loop flap (Fig. 14). The lower two hook and loop straps are wrapped
around the tubes of the footrest.
If necessary, the additional pad can be removed.
