Control Box 3S io

PROduCT dESCRIPTION

The CONTROL BOX 3S is designed to control one or two Somfy 24V motors for opening and closing gates.

uSE ANd OPERATION

Normal operation
using Keygo io type remote controls
Complete opening (Fig. 1)
Press the programmed button to open the gate fully.
Closing (Fig. 3)
using Keytis io type remote controls
Complete opening (Fig. 5)
2 s
Pedestrian opening (Fig. 6)
< 0.5 s
Closing (Fig. 7)
Copyright © 2011 Somfy SAS. All rights reserved
1
3
Pedestrian opening (Fig. 2)
Press the programmed button to open the gate in pedestrian mode.
Stop (Fig. 4)
5
6
7
2
4
STOP
4
