DETEWE DSL Speedweb OpenAttendant 205 User Manual page 8

A
C
OpenCom 105:
Using a suitable tool (a screwdriver for
example), release clips (A) to (D) from
the retaining bars and lift the cover
upwards.
CAUTION! The clips are me-
chanically stressed, so release
them carefully. Make sure that
the clips do not spring out of the
anchoring and injure you.
4. Insert the memory card in the
base on the upper edge of the
module board.
Multimedia-Karte
Inserting a multimedia-card in the
case of an OpenCom 105/110/120
6
Installing a Memory Card
B
D
Inserting a compact flash card
(OpenCom 130)
5. In the case of an OpenCom 105/
110/120: Replace the module
cover:
OpenCom 110 and
OpenCom 120: Slide the locka-
ble hooks at the lower end of the
cover into the recesses of the
connector panel module. Press
the module cover firmly until
the top lockable hooks (1) and
(2) lock into place.
OpenCom 105: Slide the clips (A)
to (D) over the retaining bar.
Press the clips lightly until they
snap in place.
6. Replace the enclosure cover.
7. Insert the mains plug.
The OpenCom 100 is restarted. The
configuration last loaded is reacti-
vated.
OpenAttendant
