1
—
7.4 m × 7.4 m
11 m × 11 m
2
—
7.5 m × 7.5 m
15 m × 15 m
3
—
7.7 m × 7.7 m
19 m × 19 m
4
—
7.8 m × 7.8 m
24 m × 24 m
5
—
7.9 m × 7.9 m
28 m × 28 m
6
—
8.1 m × 8.1 m
32 m × 32 m
7
—
8.2 m × 8.2 m
36 m × 36 m
1
—
7.5 m × 7.5 m
11.5 m × 11.5 m
2
—
7.6 m × 7.6 m
14.5 m × 14.5 m
3
—
7.6 m × 7.6 m
18 m × 18 m
4
—
7.8 m × 7.8 m
20 m × 20 m
5
—
7.8 m × 7.8 m
22 m × 22 m
6
—
8.1 m × 8.1 m
23 m × 23 m
7
—
8.2 m × 8.2 m
24 m × 24 m
HF 360
Setting detection reach (Fig� 5�2-5�4)
DUAL HF
Aiming the sensors (Fig� 4�5)
6� Maintenance / care
The product requires no maintenance.
The detector lens may be cleaned with a
damp cloth if it gets dirty (do not use cleaning
agents).
7� Disposal
Electrical and electronic equipment, acces-
sories and packaging must be recycled in an
environmentally compatible manner.
Do not dispose of electrical and
electronic equipment
as domestic waste.
EU countries only:
Under the current European Directive on Waste
Electrical and Electronic Equipment and its
implementation in national law, electrical and
electronic equipment no longer suitable for use
must be collected separately and recycled in
an environmentally compatible manner.
8� Conformity
STEINEL Vertrieb GmbH hereby declares
G B
that the DUAL HF DALI-2 / HF 360 DALI-2
radio equipment type conforms to Directive
2014/53/EU. The full wording of the EU
1
3
Declaration of Conformity is available for down-
Y E A R
Y E A R
loading from the following Internet address:
http://www.steinel.de
MANUFACTURER'S
MANUFACTURER'S
WARRANTY
WARRANTY
9� Manufacturer's Warranty
As purchaser, you are entitled to your statutory
rights against the vendor. If these rights exist
in your country, they are neither curtailed nor
restricted by our Warranty Declaration. We
guarantee that your STEINEL Professional sen-
sor product will remain in perfect condition and
proper working order for a period of 5 years.
We guarantee that this product is free from
material-, manufacturing- and design flaws.
In addition, we guarantee that all electronic
components and cables function in the proper
manner and that all materials used and their
surfaces are without defects.
Making Claims
If you wish to make a claim, please send your
product complete and carriage paid with the
original receipt of purchase, which must show
the date of purchase and product designation,
either to your retailer or contact us at
STEINEL (UK) Limited, 25 Manasty Road,
Axis Park, Orton Southgate, Peterborough,
PE2 6UP, for a returns number. For this
reason, we recommend that you keep your
receipt of purchase in a safe place until the
warranty period expires. STEINEL shall assume
no liability for the costs or risks involved in
returning a product.
For information on making claims under the
terms of the warranty, please go to
www�steinel-professional�de/garantie
10
If you have a warranty claim or would like to
ask any question regarding your product,
you are welcome to call us at any time on our
Service Hotline 01733 366700.
5
Y E A R
MANUFACTURER'S
WARRANTY
10� Troubleshooting
Malfunction
Cause
No power at the sensor ■ Fuse has tripped, not
switched ON, break
in DALI wiring
■ Short circuit
Light level not being
■ Break in wiring
communicated
■ DALI power supply faulty
Sensor sending motion
■ There is interference, e.g. fan,
detection signal when
air-conditioning system or oth-
it should not
er source of heat, in the detec-
tion zone
■ Animals moving in
detection zone
■ Wind is moving paper or plants in
the detection zone
■ Sunlight is shining on the lens
■ Sudden temperature change due
to air expelled from fans, open
windows, air-conditioning systems
or other sources of heat
■ Sensor near Wi-Fi or other wire-
less communication source
Sensor reach
■ Differing ambient temperatures
change
Remedy
■ Activate, change fuse, turn ON
mains switch,
check DALI wiring with
voltage tester
■ Check connections
■ Check cable
■ Adjust detection zone or fit
shrouds, increase distance
■ Adjust zone or fit shrouds
■ Change detection zone
■ Mount sensor in a protected place
or change zone
■ Adjust detection zone
or install in a different place
■ Install at least 2 m away from the
wireless communication source
■ Use shrouds to define detection
zone precisely
11
