Technical Specifications - Ross SRA-8901 Series User Manual

Technical Specifications

This section lists the technical specifications for the SRA-8901
Category
Number of Inputs
Data Rates and SMPTE Standards
Accommodated
Impedance
SDI Input
Equalization (Belden 1694A cable)
Return Loss
Connector Type
Number of Outputs
Impedance
Return Loss
a b
SDI Outputs
Rise & Fall Times
5–2 • Specifications
Table 5.1 Technical Specifications
Parameter
SRA-8901-4
SRA-8901-10
Specification
1
19.39Mbps, 38.78Mbps, SMPTE 310
MADI, AES10-2008
270Mbps, 525/625 Component, SMPTE 259M
270Mbps, DVB-ASI
1.485Gbps Component, SMPTE 292M
2.97Gbps Component, SMPTE 424M
5.94Gbps Component, SMPTE 2081
11.88Gbps Component, SMPTE 2082
75ohm
>380m (1640ft) @ 270Mbps
>210m (650ft) @ 1.485Gbps
>180m (490ft) @ 2.97Gbps
>80m (260ft) @ 5.94Gbps
>50m (190ft) @ 11.88Gbps
>15dB to 1.485Gbps
>10dB to 2.97Gbps
>7dB to 5.94Gbps
>4dB to 11.88Gbps
HD-BNC
4
10
75ohm
>15dB to 1.485Gbps
>10dB to 2.97Gbps
>7dB to 5.94Gbps
>4dB to 11.88Gbps
MADI: 1.0-3.0nS, <0.5nS difference
270Mbps: 0.4-1.5nS, <0.5nS difference
1.485Gbps: <270ps, <100ps difference
2.97Gbps: <135ps, <50ps difference
5.94Gbps: <80ps, <30ps difference
11.88Gbps: <45ps, <18ps difference
