ir/serial interface

The AXB-IRS4 AXLink IR/Serial Interface connects up to four remote

infrared or serial devices to AMX Control Systems.

Each port in the AXB-IRS4 can store up to 200 programmed commands

to control IR or serial devices, such as audio and video cassette recorders,

compact disc players and tuners.

The AXB-IRS4 generates programmed commands specific to each device

by manufacturer, model number and function. Port-by-port programmability

means you can easily upgrade your system as technological advances are

made in audiovisual equipment.

Need help?

Do you have a question about the AXB-IRS4 and is the answer not in the manual?

Page 1 The AXB-IRS4 AXLink IR/Serial Interface connects up to four remote infrared or serial devices to AMX Control Systems. Each port in the AXB-IRS4 can store up to 200 programmed commands to control IR or serial devices, such as audio and video cassette recorders, compact disc players and tuners.
Page 2 AXB-IRS4 (FG5914) • Controls up to four IR or serial devices • Stores up to 200 control commands in each port (28K total memory) • Supports 300–19,200 baud transmission rates for stand-alone PC control • Emulates four devices on the AXLink bus •...
