4.

Laser Safety

The scanCONTROL 30xx sensors operate with a semiconductor laser with a
wavelength of 658 nm (visible/red). Operation of the laser is indicated visually by the
LED on the sensor, see operating instructions Chap. 3.3. When operating the scan-
CONTROL 30xx sensors, the relevant regulations according to IEC 60825, Part 1 of
05/2014 and the applicable accident prevention regulations must be followed. The laser
warning labels for Germany have already been attached. For other non German speak-
ing countries, an IEC standard label is included in delivery and the versions valid for the
user's country must be attached before the device is put into operation for the first time.
i
If both warning labels are covered over when the unit is installed, the user must
ensure that supplementary labels are applied.
Laser Class 2M
The sensors fall within laser class 2M (IIM). The laser is operated on a pulsed mode, the
maximum optical power is ≤ 10 mW or ≤ 12 mW. Attach the following warning labels to
the cover (front and rear side) of the sensor housing.
Fig. 1 LLT30xx-25, LLT30xx-50, LLT30xx-100
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH
IEC 60825-1 ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019
Laser Class 3R
The sensors with the /3R option fall within laser class 3R. The laser is operated on a
pulsed mode, the maximum optical power is ≤ 30 mW or ≤ 50 mW. Attach the follow-
ing warning labels to the cover (front and rear side) of the sensor housing.
Fig. 3 LLT30xx-25, LLT30xx-50
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH
IEC 60825-1 ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019
i
Class 3R laser sensors require a
laser protection officer.
scanCONTROL 3010 / 3012
Laser radiation. Close your eyes or immediately turn away if the
laser beam hits the eye. Irritation or injury of the eyes possible.
LASER RADIATION
DO NOT STARE INTO BEAM
OR EXPOSE USERS OF
TELESCOPE OPTICS
CLASS 2M LASER PRODUCT
IEC 60825-1: 2014
P 10 mW, P 10 mW; E 6 mW/cm²;
0 P
λ = 658nm; F = 0...25kHz, t = 7µs...∞
Only for USA
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
IEC 60825-1: 2014
P ≤ 30mW, P ≤ 30mW; E ≤ 18mW/cm²;
0 P
λ = 658nm; F = 0...25kHz, t = 7µs...∞
Only for USA
LASER RADIATION
DO NOT STARE INTO BEAM
OR EXPOSE USERS OF
TELESCOPE OPTICS
CLASS 2M LASER PRODUCT
IEC 60825-1: 2014
P 12 mW, P 12 mW; E
0 P
λ = 658nm; F = 0...25kHz, t = 7µs...∞
Fig. 2 LLT30xx-200
i
Mark the laser area recognizable
and everlasting.
Fig. 4 LLT30xx-100, LLT30xx-200
In addition, the following information label
must be attached to the laser output on
the sensor housing:
LASER
APERTURE
6 mW/cm²;
