●Auto reference
Points of Operation pat-
tern name
input
1-point input[1]
(Flow rate
large side ON)
1 point
(1-P) 1-point input[2]
(Flow rate
small side ON)
2-point input[1]
(Flow rate
large side ON)
2-point input[2]
(Flow rate
small side ON)
2 points
(2-P)
2-point inside
(Range inside
ON)
2-point outsid
(Range outside
ON)
Discontinue
Description
ON when higher than input point.
Set-point=input point
OFF when higher than input
point.
Set-point=input point
ON when higher than centre
value of two input points
（Input1＋Input2）
（Set-point： ）
2
OFF when higher than centre
value of two input points
（Input1＋Input2）
（Set-point： ）
2
ON when flow rate level is within
two input points.
（Set-point1：input point1）
（Set-point2：input point2）
OFF when flow rate level is
（Set-point1：input point1）
（Set-point2：input point2）
Operation waveform
ＯＮ
ＯＦＦ
Set-point
ＯＮ
ＯＦＦ
Set-point
ＯＮ
ＯＦＦ
Set-point
ＯＮ
ＯＦＦ
Set-point
ＯＮ
ＯＦＦ
Set-point
ＯＮ
ＯＦＦ
Set-point
−30−
OPERATION
LCD display
Flow rate
Flow rate
Flow rate
Set-point
Flow rate
Set-point
Flow rate
Set-point
Set-point Flow rate
[SM-385853-A]
２
