CKD WFC Series Instruction Manual

Capacitance electromagnetic flow sensor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
I
nstruction manual
Capacitance Electromagnetic Flow Sensor
WFC
series
Thoroughly read this instruction manual
●
before using the sensor.
Please read safety instructions carefully.
●
Keep this manual near the sensor where all
●
concerned personnel have easy access to it.
ＳＭ−Ａ０９１８６−Ａ  /2
Jul.21.2020

Advertisement

Table of Contents
loading

Related Manuals for CKD WFC Series

Summary of Contents for CKD WFC Series

  • Page 1 ＳＭ−Ａ０９１８６−Ａ  /2 nstruction manual Capacitance Electromagnetic Flow Sensor series Thoroughly read this instruction manual ● before using the sensor. Please read safety instructions carefully. ● Keep this manual near the sensor where all ● concerned personnel have easy access to it. Jul.21.2020...
  • Page 2 INDEX Capacitance Electromagnetic Flow Sensor WFC Series Instruction Manual No. SM-A09186-A /2 Safety precautions・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ Cautions when using・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-1 Cautions for design and selection・・・・・・・・・・・・・・・・・・・・・・ 2-2 Cautions for mounting, piping, and wiring・・・・・・・・・・・・・・・・ 2-3 Cautions in operation・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2-4 Cautions for inspection and maintenance・・・・・・・・・・・・・・・...

  • Page 3: Safety Precautions

    1. Safety precautions When designing and manufacturing a device using CKD products, the manufacturer is obligated to check that device safety mechanical mechanism or water control circuit and the system operated by electrical control that controls the devices is secured.
  • Page 4 ●Guarantee coverage If any failure for which CKD CORPORATION is recognized to be responsible occurs within the above warranty period, a substitute or necessary replacement parts shall be provided free of charge, or the product shall be repaired free of charge at the plant of CKD CORPORATION.

  • Page 5: Cautions When Using

    2. Cautions when using Cautions for design and selection ◆Working fluid◆ ■ Do not use this product for drinking water. DANGER: This product does not comply with the Food Sanitation Act and must not be used to measure water intended for human consumption. Use this product solely as an industrial sensor.
  • Page 6 ■Maximum working pressure Do not use this product at a pressure exceeding the maximum operating pressure; otherwise, it can cause product failure. To prevent the pressure from exceeding the maximum operating pressure, particularly due to water hammer, take the following measures: Use a water hammer reduction valve, or a similar mechanism, and regulate the valve closing speed.
  • Page 7 Cautions for mounting, piping, and wiring ◆Piping◆ ■Pipes can be installed in any orientation, including vertical and horizontal, provided CAUTION: that they are installed so that the fluid constantly fills the piping as it flows through the pipes. When installing a pipe vertically, making the fluid flow upward can reduce the influence of air bubbles inside.
  • Page 8 ■When installing a piping or fitting to the product, hold the socket that is on the CAUTION: attaching side with a tool. Holding the socket that is on the opposite side or the body may cause damage. ■ Make sure that no sealing tape or adhesive enters the pipes when connecting the piping.

  • Page 9: Cautions In Operation

      ■ There is a risk of electric shock on touching the electrical wiring connections. CAUTION: ■ Always turn the power OFF before carrying out wiring. Never touch the live parts with wet hands. ■ It is recommended to electrically isolate the power supply and receiver from other points.
  • Page 10 3. Product 3-1 With IO-Link, fluid temperature measurement function Specifications/ How to order Specifications or C6931 ―9― [SM-A09186-A /2]...
  • Page 11 How to order ―10― [SM-A09186-A /2]...
  • Page 12 3-2 Standard Specifications/ How to order Specifications or C6931 ―11― [SM-A09186-A /2]...
  • Page 13 How to order ―12― [SM-A09186-A /2]...
  • Page 14 Internal structure and parts list or C6931 Dimensions ―13― [SM-A09186-A /2]...
  • Page 15 ● Cable option ● Bracket option ―14― [SM-A09186-A /2]...

  • Page 16: Installation

    4.    Installation  ・ When installing the flow rate sensor, refer to the notes on use in "2-2 Cautions for mounting, piping, and wiring ". For the water quality and installation location, please refer to "2-1 Cautions for design and selection"...

  • Page 17: Wiring Method

    Wiring method ・ When wiring, be sure to refer to precautions on use. 1) and 2) are used with the "With IO-Link, fluid temperature measurement" wiring diagram, and 3) and 4) are used with the "Standard" wiring diagram. ―16― [SM-A09186-A /2]...

  • Page 18: Operation

    5. Operation 5-1 Functions and measurement mode ―17― [SM-A09186-A /2]...
  • Page 19 Output modes and output operations ・Please note that the operation method differs depending on the model No. 5-2-1 Switch Output (SIO) Mode ―18― [SM-A09186-A /2]...
  • Page 20 5-2-2 Mode Selection 5-2-3 Normal Operation (Measurement Mode) [ Regarding Model No. WFC-□□□-□□□-C/CT/T ] ―19― [SM-A09186-A /2]...
  • Page 21 ※ It is a function that has been added to Ver.2.04 or later. The version is displayed at power-up. ―20― [SM-A09186-A /2]...
  • Page 22 [ Regarding Model No. WFC-□□□-□□□-NV/NA/PV/PA ] ―21― [SM-A09186-A /2]...
  • Page 23 ―22― [SM-A09186-A /2]...
  • Page 24 5-2-4 Easy Setup (Shortcut Mode) ※ "IO-Link Output1" setting is a feature added since Ver.2.04. The version is displayed at power-up. ※ "IO-Link Output1" setting is a feature added since Ver.2.04. The version is displayed at power-up. ―23― [SM-A09186-A /2]...
  • Page 25 5-2-5 Basic Settings (Function Mode I) ―24― [SM-A09186-A /2]...
  • Page 26 [ Regarding Model No. WFC-□□□-□□□-C/CT/T ] [ Regarding Model No. WFC-□□□-□□□-NV/NA/PV/PA ] ―25― [SM-A09186-A /2]...
  • Page 27 ―26― [SM-A09186-A /2]...
  • Page 28 [ Regarding Model No. WFC-□□□-□□□-C/CT/T ] ※ "IO-Link Output1" setting is a feature added since Ver.2.04. The version is displayed at power-up. ―27― [SM-A09186-A /2]...
  • Page 29 [ Regarding Model No. WFC-□□□-□□□-NV/NA/PV/PA ] ―28― [SM-A09186-A /2]...
  • Page 30 5-2-6 Advanced Settings (Function Mode II) ―29― [SM-A09186-A /2]...
  • Page 31 [ Regarding Model No. WFC-□□□-□□□-C/CT/T ] [ Regarding Model No. WFC-□□□-□□□-NV/NA/PV/PA ] ―30― [SM-A09186-A /2]...
  • Page 32 ―31― [SM-A09186-A /2]...
  • Page 33 ―32― [SM-A09186-A /2]...
  • Page 34 IO-Link [model No.] [Item] 5-3-1. General 5-3-2. On demand data ① Identification ② Parameter and commands 5-3-3. Process data IN 5-3-4. Observation 5-3-5. Diagnosis 5-3-1. General Item  Detail  Communication Protocol  IO-Link  Communication Protocol Version  V1.1  Bitrate  COM2（38.4kbps）  Connection  M12 Class A  Process Data Input Length  4bytes  Process Data Output Length  0byte  Minimum Cycle Time ...
  • Page 35 60L ( 2174980  0x213004  WFC-600- -CT  ⃞⃞⃞ Index  Sub  Value  Access  Item  Length  Format (Hex)  Index  (Dec)  *1  0x0010  0  Vendor Name  CKD Corporation  R  64bytes  String  0x0011  0  Vendor Text  http://www.ckd.co.jp/  R  64bytes  String  0x0012  0  Product Name  WFC-150-10A-C *2  R  64bytes  String  0x0013  0 ...

  • Page 36: Common Specification

    ② Parameter and commands Common specification  Index Value Access Item Length Format (Hex) Index (Dec) System 0x0002 *See the table below 1byte UInteger8 － Command Device Access 0x0000：Unlocked 0x000C 2bytes Record ● Locks 0x0001：Parameter Lock 0x0002：Data Storage Lock 0x0020 Error Count 2bytes UInteger16 － 0x0024 Device Status 1byte UInteger8 － Detailed Devices Array[9] of 0x0025...
  • Page 37 Individual specification  Index Value Access Item Length Format (Hex) Index (Dec) Change 0:Instantaneous flow rate ● 0x0040 1byte UInteger8 Main Display 1:Accumulated flow 0:Unlock ● 0x0041 Key lock 1byte UInteger8 1:Lock － 0x0042 OUT1 0:IO-Link 1byte UInteger8 － 0x0043 OUT2 0:NC 1byte UInteger8 0:Flow direction 1:OUT1 Change 2:OUT2 ●...
  • Page 38 Index Value Access Item Length Format (Hex) Index (Dec) 0:Normally Open ● 0x004D IO-Link Output1 contact 1byte UInteger8 1:Normally Closed IO-Link Output1 ● 0x004E *See Table 1 1byte UInteger8 Integrated flow pulse rate 0:Normally Open ● 0x004F IO-Link Output2 contact 1byte UInteger8 1:Normally Closed IO-Link Output2 ● 0x0050 *See Table 1 1byte UInteger8 Integrated flow pulse rate 2:0.10s 4:0.25s 6:0.5s ●...
  • Page 39 Index Value *3 Access Item Length Format (Hex) Index (Dec) Output1 0 to 85 0x010A ● 2bytes UInteger16 Window mode 【0 to 85℃】 Temperature upper limit Output1 0 to 84 0x010B ● 2bytes UInteger16 Window mode 【0 to 84℃】 Temperature lower limit Output1 0 to 83 0x010C ● 2bytes UInteger16 Window mode 【0 to 83℃】 Temperature hysteresis Output2 ● 0x010D *See Table 2 R/W 2bytes UInteger16 Hysteresis mode...
  • Page 40 Table 1 WFC-150  WFC-600 0:0.1L/Pulse  0:0.01L/Pulse  1:1L/Pulse  1:0.1L/Pulse  2:10L/Pulse  2:1L/Pulse  3:0.2L/Pulse  *1.        area：Factory Settings  Table 2 Hysteresis mode Model No. Threshold Hysteresis 0, 5 to 150  0 to 149  WFC-150  【0, 0.5 to 15.0L/min】  【0 to 14.9L/min】  0, 20 to 600  0 to 599  WFC-600  【0, 2.0 to 60.0L/min】  【0 to 59.9L/min】  *1.        area：Factory Settings  Table 3 Window comparator mode  Model No. Upper Limit Lower Limit Hysteresis ...
  • Page 41 5-3-3 Process data IN  Bit  31  MSB                              Data  Instantaneous flow rate Range  *See Table 4  Format  UInteger16  13 12 11 10 Switch output Data Error Warn Fluid temperature *1 True/False -10 to 110 【-10 to 110℃】 Range Boolean Integer8 Format *1. Only for...
  • Page 42 5-3-4 Observation Index  Sub  Value  Access Item  Length  Format  (Hex)  Index (Dec)  *1  Peak Hold Q Max  0x0400  0  (Instantaneous Flow Rate) *See Table 5  R  2bytes  UInteger16 Peak Hold Q Min  0x0401  0  (Instantaneous Flow Rate) 0x0402  Peak Hold T Max  0  (Temperature)  *2  -10 to 110  R  1byte  Integer8  【-10 to 100℃】 0x0403  Peak Hold T Min  0  (Temperature)  *2  Integrated Flow Rate ...

  • Page 43: Specification

    5-3-5 Diagnosis Event Code Type  Device Status Cause  Treatment method  (Hex)  Out of  Check the ambient  0x4210  Warning Device temperature over-run  specification temperature  0x5100  Error  Failure  Power supply fault  Check supply power  0x6320  Error  Failure  Memory abnormality  Turn ON the power again  Flow rate is over 1.2 times  Use the flow rate  0x8C20  Error  Failure  of F.S. within the range of FS Temperature Sensor is  The fluid temperature    0x8D06  Error  Failure  over 110°C should be 85 °C or less Temperature Sensor is ...

  • Page 44: Maintenance

    Maintenance Prohibition of disassembly and modification CAUTION: ● Since this product is a very precise sensor, you cannot exchange parts and repair it by the customer. ● Do not disassemble this product. Products reassembled after disassembly cannot meet the specifications. ●...

  • Page 45: Troubleshooting

    Wear and scratches on O-ring. Contact the dealer. Looseness of screws and bolts. Tighten the screws and bolts sufficiently. Body is abnormally Damaged internal circuit. Stop use immediately and contact the dealer. hot. *For other troubles, consult with CKD. ―44― [SM-A09186-A /2]...
