Summary of Contents for VeEX VePAL TX300
- Page 1 VF TESTING VePAL TX300 T he Veri fication E xper ts...
- Page 2 VF TESTING VePAL TX300 Quick Reference Guide TX300 Test Set...
- Page 3 VF TESTING VePAL TX300 Quick Reference Guide Home Menu The Home menu can be accessed at anytime during operation by pressing the Home key on the rubber keypad. The screen is divided into three presentation areas: LEDs: Displays soft LEDs associated with Errors...
- Page 4 VF TESTING VePAL TX300 Quick Reference Guide DS1 Home Allows the user to set up the DS1 interfaces and associated test parameters prior to running a test. DS1 Home Menu Setup – configure Interface, Measurement and General settings; Framing, Line...
- Page 5 VF TESTING VePAL TX300 Quick Reference Guide Configuration 1. Connect to the DS1 test interface using the Bantam connectors 2. Power on the unit 3. From the DS1 Home menu, tap on the Setup menu 4. Configure the Measurements and General settings...
- Page 6 VF TESTING VePAL TX300 Quick Reference Guide Setup and Results Setup − Time Slot - Channel to test for both transmitting and receiving: Options: 1 - 24 − Mode – Talk or send a Tone on the transmit signal. Transmit audio data from the external headset into selected timeslot.
- Page 7 VF TESTING VePAL TX300 Quick Reference Guide Notes...
- Page 8 Quick Reference Guide Notes © 2011 VeEX Inc. All rights reserved. VeEX Inc. VeEX is a registered trademark of VeEX Inc. The 2827 Lakeview Court information contained in this document is accurate. Fremont, CA 94538 USA However, we reserve the right to change any Tel: +1.510.651.0500...
