WATTrouter ECO - user manual
Solid state relay (SSR) does not
switch on
Data in statistics don't
correspond with reality
Statistics suddenly erased
SC-Gateway or SC-Router
module is inserted in regulator,
but all Link LEDs are off
Wireless peripheral can't be
registered, even after longer
period while connected. Window
Add wireless station is not
displayed.
Wireless station does not switch
or switches incorrectly
After inserting the SC-Router
How to fit and setup the device
SSR is not connected
correctly
Incompatible relay
Regulator failure/defect
SSR failure/defect
This is normal
This is normal
Wrong polarity of the
module
Regulator or module
failure/defect
Station out of signal range
Station is incompatible
Stations is defective
SC-Gateway module does
not react
SC-Gateway module
failure/defective
Station out of signal range
Stations is defective
SC-Gateway module does
not react
The master controller
Check for proper terminal connection and
observe polarity of SSR anodes.
Always use a SSR with zero cross switch and
minimum DC control voltage of 4VDC.
Replace the regulator or take it to repair.
Replace the SSR.
The data are indicative only; the device
does not have accurate data from
utility/billing meters. Furthermore, the
device may be configured improperly, i.e.
does not evaluate the same as your utility
meter does.
There was a date change in the controller or
power failure during writing the history into
EEPROM after midnight.
Remove and insert module once again
based on installation manual of the module.
Replace the module or regulator or take
them to repair.
Test the wireless peripheral so it is placed
temporary closer to the regulator. Once this
time it is detected, there is necessary to
extend signal range with signal repeater.
Consult this problem with technical
support.
It is different type of wireless peripheral,
which is not compatible with SC-Gateway
module.
Follow the installation manual for the
wireless peripheral.
Reset the controller and wait about 1
minute. Then repeat the network
registration procedure.
Replace the module or take it to repair.
Test the wireless peripheral so it is placed
temporary closer to the regulator. Once this
time it is detected, there is necessary to
extend signal range with signal repeater.
Consult this problem with technical
support.
Follow the station manual
Reset the controller and wait about 1
minute. Then test the function of the
peripheral.
Follow the steps mentioned above.
