WATTrouter ECO - user manual

DEVICE CONFIGURATION

You will need notebook or regular PC (placed closely enough to the regulator) with USB interface (hereinafter
referred to as a computer only). The controller is configured using the WATTconfig ECO control software. The
installation package for this software is available on manufacturer's web pages. Before installing the
WATTconfig ECO control software you need to install the driver for USB interface.
In order to connect to the USB interface, it is necessary - due to safety reasons - to turn off the
entire distribution box before manipulation.
If you cannot continue with the settings (due to any reasons), proceed according to instructions specified in the
Troubleshooting chapter.

USB DRIVER INSTALLATION

The installation procedure is described for Windows XP, English locale. The procedure is similar for newer
systems, or it is much simpler. Newer versions of operating systems (Windows, Linux, MAC OS) usually already
have these drivers pre-installed so you can skip reading further paragraphs.
1. Insert the attached USB cable to the USB connector of the regulator and then to the computer.
2. Turn on the controller. The green LED PWR must light up (power on indication). Also the yellow LED
COM light will or should flash briefly (communication process indication) as the USB device will start to
register in your computer.
3. After a moment, following window must appear confirming that a new device was found:
4. Select: No, not this time. In the following window select: Install from a list or specific location
(Advanced).
