WATTrouter ECO - user manual

TROUBLESHOOTING

The following table shows the most frequent problems and usual solutions:
Problem description
The controller has been fitted
according to the manual but
after you switch on the circuit
breaker no LED lights up or
flashes.
The controller has been fitted
according to the manual but
after you turn on the circuit
breaker the green LED quickly
flashes, the controller does not
work and the WATTconfig ECO
software shows all zeros.
The controller does not
communicate with computer
Measured powers are not
displayed or they are displayed
incorrectly
How to fit and setup the device
Possible causes
The circuit breaker is on
but the supply voltage is
missing.
Regulator failure/defect
The controller runs in the
boot mode without any
application firmware
The regulator has no
voltage
Computer is not properly
connected with the
controller
Computer cannot detect
connected controller.
USB interface driver was
not correctly installed in
your computer
USB interface driver is not
configured properly
The Log window records
communication errors
Regulator failure/defect
The current sensing
module is not connected
Incorrect phase sequence
Solution
Check or measure whether there is any
voltage between terminals L and N.
Replace the regulator or take it to repair.
Use the WATTconfig software and load the
newest firmware version or load the version
you prefer
Check whether green LED PWR is on and
the regulator is powered.
Check the USB cable connection, try using
different network cable, or try the cable
with different device (printer for example).
Check USB cable connection. When USB
device is being registered in your PC, the
yellow LED COM must flash temporarily.
Make sure the USB interface driver is
correctly installed and Windows device
manager detects it as a USB serial converter
and USB serial port.
Use the USB/COM interface driver
configuration window in WATTconfig ECO
and reset all parameters back to default
values and choose correct port.
A very few communication errors is
considered a common status and it depends
on the actual load put on the operating
system in your computer or on the
operating system running in the controller
or disturbance on communication line.
However, if there are many errors inspect
the functionality of your PC, or it may also
be a conflict at the USB interface in your PC.
Replace the regulator or take it to repair.
Connect the current sensing module
according to this manual.
Make sure that for all ILx inputs the "Phase"
field is correctly set. Perform the settings
