WATTrouter ECO - user manual

LED STATUSES

The following table shows possible controller statuses indicated by built-in LEDs.
LED
LED PWR (green)
LED COM (yellow)
LED ERR (red)
LED OUT
LED PWR (blue) under the lid of
regulator.
LED LINK (yellow) under the lid of
regulator.
How to fit and setup the device
Status
On
Flashes
Flashes quickly
Off
Off
Stays on or flashes quickly
Off
Flashes regularly in the following
way: short- short- short
Flashes regularly in the following
way: long- long- short
Flashes regularly in the following
way: long- long- long
Off
On or flashes quickly
Off
Flashes quickly
Flashes slowly
Off
On or flashes quickly
www.solarcontrols.cz
Note
The controller is switched on and
no output is active.
The controller is switched on and
some outputs are active.
The controller is switched on and
boot mode is active.
The controller is without power
supply or there is a failure.
Communication with computer
via USB was not established.
Communication with computer
via USB was established.
No error status detected.
L1 voltage is missing. Proceed
according to instructions specified
in the chapter Measured
parameters and statuses .
DC source overload. Proceed
according to instructions specified
in the chapter Measured
parameters and statuses.
Only when equipped with SC-
Router module:
No signal from a master system.
The relevant output is not active.
The output is active (switched on)
SC-Gateway module is not
powered or module error.
SC-Gateway module is being
initialized after power on.
SC-Gateway module has been
initialized and running.
No wireless communication.
Indicates wireless communication.
