Kramer VS-6464DN-EM Quick Start Manual

Scan for full manual
Step 1: Check what's in the box
VS-6464DN-EM 8x8 to 64x64 Modular Multi-Format Managed
Digital Matrix Switcher
Infrared remote control transmitter with batteries (for future use)
Step 2: Get to know your VS-6464DN-EM
# Feature
1 Double- Menu
function Button
2
Selector Functions
3
Buttons
Area
4
5
6
7
8
VS-6464DN-EM Quick Start
VS-6464DN-EM Quick Start Guide
This guide helps you install and use your
Go to www.kramerav.com/downloads/VS-6464DN-EM
firmware upgrades are available.
Function
ESC Press to exit the current operation.
EDID Press to assign EDID channels.
STO Press to store the current setup in a preset. After pressing the MENU button, this button
lights and is enabled.
ALL Press to connect an input to all outputs. After pressing the MENU button, this button lights
and is enabled.
OFF Press to turn off an output. After pressing the MENU button, this button lights and is
enabled.
RCL Press to recall a preset. After pressing the MENU button, this button lights and is enabled.
DELAY Press to set the delay between confirming an action and the execution of the action.
ENT Press to complete the input-output setup when using a one-digit number instead of two
digits. For example, to enter input 5, you can press either 05 or 5, ENT.
Press to enter the options in a setup menu.
VS-6464DN-EM for the first time.
to download the latest user manual and check if
1 Power cord
1 Set of rack ears (attached)
P/N: 2 9 0 0 - 3 0 1 3 8 6 QS
1 Quick start guide
Rev: 3
