Kramer VS-6464DN-EM Quick Start Manual

VS-6464DN-EM Quick Start Guide
This guide helps you install and use your VS-6464DN-EM for the first time.
Go to
Scan for full manual
firmware upgrades are available.
Step 1: Check what's in the box
VS-6464DN-EM 8x8 to 64x64 Modular Multi–Format Digital Matrix Switcher
Infrared remote control transmitter with batteries
Step 2: Get to know your VS-6464DN-EM
# Feature
1
2
3
Double-
function Menu
4
Selector Button
Buttons Functions
5
Area
6
7
VS-6464DN-EM Quick Start (P/N: 2900-300902QS REV 1)
www.kramerav.com/downloads/VS-6464DN-EM
Function
ESC Press to exit the current operation.
Press to assign EDID channels.
EDID
STO Press to store the current setup in a preset. After pressing the MENU button, this button lights
and is enabled.
ALL Press to connect an input to all outputs. After pressing the MENU button, this button lights and
is enabled.
OFF Press to turn off an output. After pressing the MENU button, this button lights and is enabled.
RCL Press to recall a preset. After pressing the MENU button, this button lights and is enabled.
DELAY Press to set the delay between confirming an action and the execution of the action.
to download the latest user manual and check if
1 Power cord
1 Set of rack ears (attached)
P/N:
2900- 300902QS
1 Quick start guide
Rev:
1
