Table 5 J3- MCU UART0 and SWD
Pin Name
1 SWDCLK
2 SWDIO
3 +3.3 V
4 GND
5 GND
6 +3.3 V
7 P2.0 (RXD0_A)
8 P2.1 (TXD0_A)
Table 6 J4- iMOTION Link
Pin Name
1 SWDCLK
2 SWDIO
3 +3.3 V
4 GND
5 GND
6 +3.3 V
7 RXD0
8 TXD0
Table 7 J5- MCU IO connection
Pin Name
1 P2.1 (TXD0_A)
2 P2.2
3 P2.0 (RXD0_A)
4 P2.6
5 P4.7
6 P2.8
7 P4.6
8 P2.10
9 GND
10 P2.11
Table 8 J6- MCU I/O connection
Pin Name
1 P1.1
2 P1.0
3 +3.3 V
4 GND
User Guide
Pin name connectors
User serial debug clock
User serial debug I/O
+3.3 V power supply
Ground
Ground
+3.3 V power supply
MCU serial port 0, RXD
MCU serial port 0, TXD
Pin name connector
User serial debug clock for MCU
User serial debug I/O for MCU
+3.3 V power supply
Ground
Ground
+3.3 V power supply
Reception of UART0 for MCE
Transmission of UART0 for MCE
Pin name connector
Programmable I/O, or MCU serial port 0, TXD
Programmable I/O
Programmable I/O , or MCU serial port 0, RXD
Programmable I/O
Programmable I/O
Programmable I/O
Programmable I/O
Programmable I/O
Ground
Programmable I/O
Pin name connector
Programmable I/O
Programmable I/O
+3.3 V power supply
Ground
