Festo CMMT-ST-C8-1C-S0 Series Operating Instructions Manual page 6

[X1A] Pin
1
2
3
4
5
6
7
8
9
10
Tab. 13: Inputs and outputs for the higher-order PLC
The inputs and outputs are configured using the CMMT-ST plug-in è online help
for the CMMT-ST plug-in.
The signals of inputs STO-A/B are low active, so they are marked with #.
Requirements for the connecting cable
Shielding
Min. conductor cross section incl. wire end sleeve with plastic
1)
sleeve
Max. conductor cross section incl. plastic wire end sleeve
Max. length
1) The conductor cross section used must be suitable for the expected currents. If flexible flying leads are
used with plastic wire end sleeves, minimum cross sections of 0.14 mm² are possible.
Tab. 14: Requirements for the connecting cable
7.4.2 [X1C], reference switch/limit switch
The connection [X1C] is located on the front of the device and is used to connect
the reference switch or a limit switch. The switching logic of the input can be
parameterised (PNP logic or NPN logic).
[X1C] Pin
1
2
3
Tab. 15: Connection for the reference switch/limit switch
Cable requirements
Shielding
Min. conductor cross section incl. wire end sleeve with plastic
sleeve 1)
Max. conductor cross section incl. plastic wire end sleeve
Max. length
1) The conductor cross section used must be suitable for the expected currents.
Tab. 16: Cable requirements
7.4.3 [X2], encoder interface
The encoder interface [X2] is located on the front side of the device. Communica-
tion with the encoder is performed via this interface. The encoder signals are
received, and the encoder is supplied with voltage.
The following encoders are supported:
– Incremental encoders with AB signals (quadrature encoder)
– Absolute encoders with BiSS C protocol
Function Description Mating plug
labelling
+ 24 V, out + 24 V DC output 1
(fused)
#STO-A Control input STO-A
Safe torque off,
channel A
#STO-B Control input STO-B
Safe torque off,
channel B
STA-C1 Diagnostic con- STA
tact STA Safe
STA-C2
torque off
acknowledge
CTRL-EN Power stage 6
enable/acknowl-
edge error
Basic in 01 configurable 7
input
Basic in 02 configurable 8
input
Basic out 01 configurable 9
output
Basic out 02 configurable 10
output
not required
0.2 mm
2
1.5 mm
2
25 m
Function Description Mating plug
labelling
+24 V, out + 24 V DC output +
(fused)
REF/IN Reference IN
signal/limit
switch signal
0 V/GND Reference -
potential, refer-
ence switch
not required
0.14 mm 2
1.5 mm
2
25 m
[X2] Pin
1
2
3
4
5
6
7
8
Tab. 17: Incremental encoders with AB signals (quadrature encoder)
[X2] Pin
1
2
3
4
5
6
7
8
Tab. 18: Absolute encoders with BiSS C protocol
Requirements for the connecting cable
Shielding
2)
Min. cable cross section
Max. conductor cross section
Max. length
1) Festo screened cables can be used. The shield can only be connected on the motor side.
2) The conductor cross section used must be suitable for the expected currents. If flexible flying leads are
used with plastic wire end sleeves, minimum cross sections of 0.14 mm² are possible.
Tab. 19: Requirements for the connecting cable
7.4.4 [X18], standard Ethernet
The interface [X18] is located on the front of the device. The following can be
performed via the interface [X18] using the commissioning software:
– Diagnostics
– Parameterisation
– Controller
– firmware update
The interface fulfils the requirements of standard IEEE 802.3:2012. The interface
is galvanically isolated and intended for use with limited cable lengths.
The connection [X18] is designed as an RJ45 bushing. 2 LEDs are integrated into
the RJ45 bushing. The green LED lights up if the interface is activated. The yellow
LED flashes when communication activity is detected.
Requirements for the connecting cable
Characteristics
Max. cable length
Tab. 20: Requirements for the connecting cable
The following connections are possible via the Ethernet interface:
Connections
Point-to-point connection
Network connection
Tab. 21: Options for connection
The device supports the following methods of IP configuration (based on IPv4):
Function Description Mating plug
labelling
A_IN A signal input 1
B_IN B signal input 2
IDX_IN Index signal 3
input
+5 V 5 V encoder 4
supply
#A_IN A signal input, 5
inverse
#B_IN B signal input, 6
inverse
#IDX_IN Index signal 7
input, inverse
GND Reference 8
potential of
encoder supply
Function Description Mating plug
labelling
– – 1
MA+ Clock line BiSS 2
C, output
SLO+ Data transmis- 3
sion line BiSS C,
input
+5 V 5 V encoder 4
supply
– – 5
MA– Clock line BiSS 6
C, output
inverse
SLO– Data transmis- 7
sion line BiSS C,
input inverse
GND Reference 8
potential of
encoder supply
1)
Not required but twisted in pairs
0.2 mm 2
1.5 mm
2
25 m
CAT 5, patch cable, double shielded
30 m
Description
The device is connected directly to the PC via an
Ethernet cable.
The device is connected to an Ethernet network.
