π
H-7690
ERGO MESH CHAIR
PARTS LIST
1
Caster x 5
2
5-Star Base x 1
4
5
Gas Lift x 1
Mechanism x 1
Back Cushion
7
8
Armrest x 2
Kit x 1
Screw x 1
Screw x 2
10
11
8 x 10 mm
4 x 20 mm
13
M5 Allen Wrench
PAGE 1 OF 6
1-800-295-5510
uline.com
Step 1
3
Gas Lift Cover x 1
6
Seat Cushion x 1
Screw x 14
9
6 x 24 mm
Step 4
Screw x 1
12
10 x 23 mm
ASSEMBLY INSTRUCTIONS
Step 2
3
4
2
1
Seat Slider
Step 5
Lever
9
5
NOTE: May need to adjust seat
slider in order to tighten screws.
Pull out seat slider lever and
move mechanism forward or
backward.
Pour le français, consulter les pages 5-6.
Step 3
13
10
7
NOTE: "Outward" is shown on
back of brace. This side of
brace should face outward.
13
12
11
Para Español, vea páginas 3-4.
13
9
6
8
0720 IH-7690
Advertisement
Table of Contents
Related Manuals for U-Line ERGO H-7690
Summary of Contents for U-Line ERGO H-7690
- Page 1 Para Español, vea páginas 3-4. π H-7690 1-800-295-5510 Pour le français, consulter les pages 5-6. uline.com ERGO MESH CHAIR PARTS LIST ASSEMBLY INSTRUCTIONS Step 1 Step 2 Step 3 Caster x 5 5-Star Base x 1 Gas Lift Cover x 1 Gas Lift x 1 Mechanism x 1 Seat Cushion x 1...
- Page 2 CHAIR ADJUSTMENTS 4. Seat Depth Adjustment (Seat Slider) – To increase depth of seat, pull lever out and move body forward while sitting. To decrease depth, pull lever out and move body backwards while sitting. 5. Seat Height Adjustment – To raise seat height, lift lever up with little to no weight on the seat.
- Page 3 π H-7690 800-295-5510 uline.mx SILLA ERGONÓMICA DE MALLA LISTA DE PARTES INSTRUCCIONES DE ENSAMBLE 1 Cubierta para Paso 1 Paso 2 Paso 3 5 Ruedas 1 Base Estrella Pistón de Gas 1 Pistón de Gas 1 Mecanismo 1 Asiento NOTA: Se muestra "Outward" en la parte posterior del 1 Kit para 14 Tornillos...
- Page 4 AJUSTES DE LA SILLA 4. Ajuste de la Profundidad del Asiento (Deslizador del Asiento) – Para aumentar la profundidad del asiento, jale la palanca y mueva su cuerpo hacia adelante mientras esté sentado. Para disminuir la profundidad, jale la palanca y mueva su cuerpo hacia atrás mientras esté...
- Page 5 π H-7690 1-800-295-5510 uline.ca ERGO – CHAISE EN MAILLE LISTE DES PIÈCES INSTRUCTIONS DE MONTAGE Protection de vérin Base à 5 Étape 1 Étape 2 Étape 3 Roulette x 5 pneumatique x 1 branches x 1 Vérin Mécanisme x 1 Siège x 1 pneumatique x 1 REMARQUE : «...
- Page 6 RÉGLAGES DE LA CHAISE 4. Réglage de la profondeur d'assise (assise coulissante) – Pour augmenter la profondeur d'assise, tirez le levier vers l'extérieur et bougez vers l'avant en position assise. Pour diminuer la profondeur, tirez le levier vers l'extérieur et bougez vers l'arrière en position assise.
