quadient IS-5000 Manual page 2

IS-6000
postage and
rate section
• For more specific information about your
mailing system, see the User Guide.
• For your installation Pin Code please monitoring
visit
www.quadient.co.uk/is6000_ug
Applying postage
1
TO RESET PREVIOUS SETTINGS...
PRESS CLEAR OR WAKE
• To get back to default rate settings,
tap on the screen.
• If the system is asleep, press
to wake it up with default settings.
Thickness setting
There is a thin/thick mail latch under the top cover of the fee-
der. For normal operation, the lever will be to the left. However,
for processing a batch of thick mail, move the lever to the right,
especially if the thicker envelopes won't feed into the mail path.
1- Open the feeder
cover.
2- Change the lever
position:
- left for normal;
- right for special
thickness
3- Close feeder
cover
Task bar
1
Imprint,
2
System
section
Menu Mailbox Direct acces button
2a
TO WEIGH YOUR MAIL...
USE THE DYNAMIC SCALE
Tap and select
•
OR
2b
PUT YOUR MAIL ON THE SCALE
• By default the weighing platform and
are automatically selected.
• Otherwise, tap then
Changing the ink tank
1- On the new ink tank, remove the protective
strips.
2- Open the ink tank drawer by pulling it towards
you.
3- Press on the blue release lever to disengage
the ink tank.
4- Pull out the old ink tank.
5- Insert the new ink tank,
then push it until you
hear the click.
6- Close the drawer. The
alignment process
of the printing heads
starts automatically.
Getting to know your mailing system
Account
1
Imprint, postage and rate section
section
Rate display
3
Processing
modes
section
ERA Slogan All rate Rate favorite
selection selection favorites shortcuts
3
CHOOSE RATE AND SERVICES
Current rate and selected services are displayed in this
area of the screen.
To change the rate and/or add services:
1- If Rate favorite button is pressed,
parameters of imprint are displayed
in the imprint details zone above.
2- Use Rate favorite button to select a
preset rate.
3- If Other rates button is pressed,
the following screen appears.
Use rate buttons 1 to 9 to select
an available Class and or Services,
or select Rate wizard.
4- Validate your selection to return to
the home screen.
If jamming occurs...
In the base:
1- Pull the release handle on the lower
assembly of the print Base.
2- Using your other hand, remove the
jammed envelopes.
If the jammed envelopes can not be
removed, perform the following.
3- Press on the blue release lever to
disengage the ink tank.
In the feeder:
1- Open the cover.
2- Gently remove jammed
envelopes.
3- Close the cover.
Ink level
2
System
monitoring section
Date Postage amount
and weight Inserter Credit
control available
Sealing mode Moistening level Weighing type
3
Processing
modes section
Other Date
Quiet mode Print offset
rates settings
4
PRINT THE STAMP
1- Press to start the motors of your mailing.
2- Insert the mail piece in the feeder loader, the
imprint printing position on the upper right side.
To print on labels:
1- Insert labels into the dispenser until a click,
printing side facing the right.
2- Tap to enter the number of labels
To seal the envelopes:
to activate or deactivate
Adding credit
Filling the sealer bottle
1- Remove the bottle
Press , and
from its base and
follow instructions on
screen. turn it over.
2- Unscrew the cap
Note: to complete this
and fill the bottle
operation successfully,
your postal services with water up to the
account must have a
limit marks.
positive credit balance
3- Screw on the cap
of the corresponding
and put the bottle
amount.
back into place.
Franking Reset
items counter
ON/OFF
Switch
Sleep/wake
PC connected
Credit
PC toggle
Stops printing
Starts printing
Label printing
.
Tap on the screen
the sealer.
