ADDAC705 Assembly Guide
STEP 6:
Place all parts on the pcb, notice the values, orientation and jack types like shown below.
A10K
B100K
Non-threaded
Jacks
Threaded Jacks
Non-threaded
ADDAC SYSTEM
Jacks
B10K
B10K
Notice
Orientation
"Round" side
facing right!
Threaded Jacks
page 7
