PEERLESS Jumbo 2000 JM 2630 Installation And Assembly Manual

Please read this information first
Read entire instruction sheet before beginning assembly
and installation.
Check parts on parts listing before beginning assembly.
Many accessories are available for this product. Please
contact customer service or visit website for more
information.
The retainer bar (D) in step 4 must be placed with ex-
truded side towards the anti rollout hook (C).
Pay close attention to the assembly of the threaded flush
mount tube (N) in step 6. The retaining collar (K) threads
up into the horizontal support (G). The set screw (W) is
then installed from the inside of that collar into the notch
in the tube. Refer to drawings for correct placement.
The placement of set screw (W) in detail 3 of step 6 is
essential to the safety of the installation.
Visit the Peerless Web Site at www.peerlessmounts.com
Installation and Assembly
- Jumbo 2000
1 of 9
Models: JM 2630, JM 2640,
®
This product is intended for use with UL
Listed products and must be installed by a
R qualified professional installer.
Product is UL rated up to ___ TV
sizes, per attached chart
Model #
JM 2630
JM 2640,
JM 2640D
JM 2650,
JM 2650D,
JM 2655
JM 2660,
JM 2665
JM 2670,
JM 2675
ISSUED: 06-02-98 SHEET #: 128-9100-10 06-21-05
For customer care call 1-800-729-0307 or 708-865-8870.
JM 2640D, JM 2650,
JM 2650D, JM 2655,
JM 2660, JM 2665,
JM 2670, JM 2675
TV size
17"
21"
27"
35"
40"
