Jensen JBS-350 Wall Mount Instructions

Hide thumbs Also See for JBS-350:

142 mm (5.59")

1/4" (6.35mm)

Drill Holes Here

JBS-350 WALL MOUNT INSTRUCTIONS

PLACE THIS WALL MOUNTING TEMPLATE AGAINST THE WALL IN THE

LOCATION WHERE YOU WANT TO MOUNT THE JBS-350.

MARK THE TWO MOUNTING HOLES

USING A PENCIL.

MAKE SURE THE MARKS ARE LEVEL PRIOR TO DRILLING HOLES IN THE WALL.

BE SURE YOUR SCREWS ARE ATTACHED TO WOOD STUDS OR ANCHORS (FOR DRYWALL)

OR CONCRETE ANCHORS (FOR BRICK/CONCRETE WALLS – NOT INCLUDED).

DETACH THE STAND FROM MAIN UNIT PRIOR TO MOUNTING ON THE WALL.
