- Page 1 Jarvis L-shaped standing desk Assembly instructions For assembly assistance, call 888-508-3725 or email support@fully.com...
- Page 2 Thank you for choosing a Jarvis desk from Fully.
- Page 3 Cautions and use Before starting Specs In the box Assembly Reset procedure Custom settings Using your own desk top Contact...
- Page 4 Any extracurricular use is at user’s own risk. Under no circumstances does the manufacturer accept warranty claims or liability claims for damage caused by improper use or handling of the desk frame. Jarvis is a registered trademark of Fully, LLC. All rights reserved.
- Page 5 Before starting On a padded or carpeted area, take all of the items out of your Jarvis frame box and confirm that nothing is missing. Reference the included parts listings on page Tools 5mm Hex Key 4mm Hex Key 3mm Hex Key (included) ( included) (included)
- Page 6 Jarvis L-shaped standing desk A— Frame End x1 B— Frame End C— Corner Frame End-A D— Corner Frame End-B (w/Capture Plate) E— Center Rail Support x1 F— Center Rails x4 G— Corner Leg x1 H— Side Leg x2 I— Foot x2 J—...
- Page 7 Assembly Step 1 Before assembling your desk, choose how you’d like your desk oriented, and decide whether you’d like the Memory Handset to be mounted on the left or the right. Lay your Desk Top on a padded workspace, top down, in the shape of an L. If you’d like the Desk Top to form an L to your left, align the smaller piece on the right side during assembly, and vice versa.
- Page 8 Step 2 Insert one of the Side Legs (you have two of these; either one works here) into the Frame End (w/Capture Plate). The Capture Plate will eventually hold your Control Box, but you don’t need to worry about that yet. B—...
- Page 9 Step 4 Select the Side Bracket that corresponds with your chosen Handset placement. If you’d like your Handset on the left, use the Left Side Bracket here; for the right side, choose the Right Side Bracket. Our illustration shows the Right Side Bracket. (Revisit the Desk Orientation Illustration on page 4 if you need help picturing what Step 2 Assembly this looks like once assembled.)
- Page 10 Step 6 Apply two Noise Attenuation Pads to Corner Frame End–A, avoiding the screw hole. G— Corner Leg x1 Insert the Corner Leg into the Corner Frame End–A. Attach the Corner Frame End to the Corner Leg by inserting two (2) Small Machine Screws into the holes on the side of the leg without a crossbar mounting plate, as displayed below.
- Page 11 Step 7 Attach the Corner Frame End–B to the Corner Leg Assembly from Step 6 with two (2) Large Machine Screws. Step 6 Assembly D— Corner Frame End–B U— Large Machine Screw x2 Now tighten all the screws from Steps 6 and 7.
- Page 12 Step 8 Apply two (2) Noise Attenuation Pads between the three screw holes on the Corner Bracket. Use two (2) Large Machine Screws to attach the Corner Bracket to the outer edge of the Corner Leg Assembly. Step 7 Assembly Wait until both screws are in place before tightening completely.
- Page 13 Step 9 Refer to the images on page 4 to confirm that the upside-down Desk Tops will result in your desired orientation when flipped over. Place a Mending Plate over the seam between the two Desk Tops, and use four (4) Wood Screws to attach the plate through the pre-drilled holes in the Desk Top.
- Page 14 Step 10 Locate the Side Leg Assembly that includes the Frame End (w/Capture Plate) from Step 4. Next you’ll attach it to the Desk Top on the side where you want the Handset to be installed. In our example, we’re installing the Handset on the right side of the desk (with the Side Leg Assembly smaller top to the left), so this Side Leg will be attached to the larger Desk Top.
- Page 15 Step 11 Slide the two (2) Center Rails into the Frame End (w/Capture Plate) you just attached to the Desk Top. Orient the Rails so the cut-out slots face each other, and are on the top side of the Center Rails, as shown. Slide the Center Rail Support halfway down the Center Rails, covering the marks Corner Leg Assembly in the middle of the Center Rails.
- Page 16 Step 12 Use five (5) screws to attach the Corner Leg Assembly to the Desk Top. Insert all screws part way before tightening them completely. Desk Top Machine Screw x5 (Included with Jarvis Desk Top) T— Wood Screw x5 AA — D esk Top Washers Important If your Jarvis Desk Top’s pre-drilled holes have metal inserts, you will need to use the Machine Screws...
- Page 17 Step 13 Slide the remaining two (2) Center Rails into the Corner Frame End attached to the Desk Top. Again, you’ll orient the Center Rails so the cut-out slots face each other and are on the top side of the Rails. Slide the final Side Leg Assembly onto the other end of the Center Rails.
- Page 18 Step 14 Secure the final Side Leg Assembly with five (5) screws. Thread all screws part way. Once they are in place, tighten them completely. Desk Top Machine Screw x5 (Included with Jarvis Desk Top) T— Wood Screw x5 AA — D esk Top Washers Step 15 Center both pairs of Center Rails between the Frame Ends.
- Page 19 Step 16 Install both Crossbars to the mounting plates on the Side and Center Legs, adjusting the width to meet each plate. It doesn’t matter which Crossbar end goes left or right, but you do want the center N— Crossbar x2 screw plate facing up.
- Page 20 Step 17 Use four (4) Small Machine Screws to fix the Crossbars in place. W— Small Machine Screw Step 18 It’s time to install your Handset. If you’re using a Jarvis Desk Top, there will be pre-drilled holes on both the left and the right sides for attaching your Handset.
- Page 21 Step 19 Slide the Control Box onto the Frame End (w/Capture Plate). The “M” sockets should face the closest leg. Plug the cable from the closest leg directly into socket M1 on the Control Box. P—Control Box x1 Use the Short and Long Leg Cables to connect the other two legs to the Control Box via the M2 and M3 sockets.
- Page 22 V— Medium Machine Screw x4 Step 21 Double check that all of the screws on the desk are fully tightened. Failure to install and tighten all screws may result in instability. Step 22 With a friend (or a few), lift the desk and gently flip it onto its Feet, supporting both the top and the frame of the desk.
- Page 23 Step 23 Initial calibration/Reset Before you start using your Jarvis, you’ll need to get all the parts synced. Don’t worry — it’s easy. Programmable Memory Handset Press and hold the ▼ icon until Jarvis reaches its lowest position. Release. Press and hold the ▼ icon until the display reads RESET. Press and hold the ▼...
- Page 24 Custom settings for Programmable Memory Handset Getting started To begin, access the menu by holding down M for 3 seconds until Lock/Unlock desk appears on screen. Use the ▴ and ▼ icons to navigate through the menu. ‘1’ selects the feature you want to change and also confirms your selection.
- Page 25 Using your own desk top There’s no one right way to position your frame on your desktop but there are a few things you’ll want to keep in mind. Generally speaking, the desktop should be centered over the frame side-to-side, and positioned slightly forward of center (towards the user) front-to-back.
- Page 26 Line up the Side Bracket from 1.a above, with the screw holes on the (larger) Side Bracket 2” from the edge, and the front-most hole at least 6.75” from the front of your desktop. Slide the Center Rails into the open Frame End from the Corner Assembly. Create the final Frame End assembly with the remaining Frame End and Side Bracket.
- Page 27 Contact Fully Portland, Oregon 888-508-3725 support@fully.com www.fully.com...
- Page 28 Desk, chairs & things to keep you moving 90.01.014.0085v.L...
