SPARE PARTS LIST
Item
1 - Front Lens Frame ..................................... 15F05
2 - Front Cover Lens (10 pcs) ......................... 15F09
3 - Shade Cartridge ........................................ 15F23
4 - Rear Cover Lens ........................................ 15F10
5 - Head Band ................................................ 15F03
6 - Sweat Band .............................................. 15F04
7 - Helmet (without shade cartridge) ............... 15F01
8 - Helmet Complete ...................................... 15F22
To remove front lens frame
grasp bottom and pull upward; to
replace, reverse process.
After removing frames, insert front
cover lens into frame.
Use only P/N 15F09 front cover
lens. Replace front lens frame.
To replace shade cartridge, push
shade cartridge outwards from
the upper inside rim. To put back,
reverse process.
F15-495 10/02
Printed in U.S.A.
4
3
P/N
A two-year warranty from the date of manufacture is given against
defects arising from faulty workmanship or materials. No war-
ranty is given against defects arising from misuse, unauthorized
interference with parts or use of the appliance which was not
intended by the manufacturer.
8
7
Magnifying Lens
- Diopter +0 ........................................................ 15F11
- Diopter +1.5 ..................................................... 15F12
- Diopter +2.0 ..................................................... 15F13
- Diopter +2.5 ..................................................... 15F14
To replace rear cover
lens, place a small
screwdriver in groove
and pull out lens.
To adjust angle of
helmet, turn
Eccentric knob.
To adjust headband, set
upper adjusting strap as
low as possible.
Warranty
6
ACCESSORIES
Push in knob (at back of
headband) and turn. It
will then click into
position.
Loosen locking-nuts and
adjust distance from eyes.
Adjust both sides at the same
time. Make sure helmet
remains straight.
The sweatband for the
forehead is removable
and washable.
5
P/N
