OPERATION
3.6.2

Logging Screen

Controls logging to the SD card.
Parameter
Log Interval
Interval Units
Status
Filename
The SD card should be formatted as FAT32.
SD card
slot
20
Figure 14
Description
Frequency of recording data to the log file
Available Options: Cycles, Seconds
Displays status information related to logging, e.g. SD card full
Automatically generated filename based on current time and date
Frost Point
-66.9
Cell Pressure
3.0
1 H20 mg/m 3
2 WVP Pa
3 H20 lbs/MMscf
4 Warnings
WARNINGS LOGGING
Figure 15
QMA401 User's Manual
Logging Screen
10
°C
barg
0
-5 -4 -3
HIGH
DP °C
LOW
Inst. Mode
TRIP
OK Next Measurement
ALARM CALIBRATE SETTINGS
Front Panel
97450 Issue 2, March 2018
-2 -1 0m
0.00
Calibration
0m
MONITOR
