Page 1: Table Of Contents
O P E R A T I N G M A N U A L FIBARO MOTION SENSOR FGMS-001 CONTENTS v2.0 #1: Description and features #6: Association #2: Basic activation #7: Z-Wave range test #3: Adding/removing the device #8: Advanced parameters... - Page 2 General information about the FIBARO System FIBARO is a wireless smart home automation system, based on the Z-Wave protocol. All of available devices can be controlled through a computer (PC or Mac), smartphone or tablet. Z-Wave devices are not only receivers, but can also repeat the signal, increasing the Z-Wave network’s range.
-
Page 3: 1: Description And Features
The sensor has a built-in accelerometer to detect any tampering of the device. FIBARO Motion Sensor is battery powered device and designed to be installed quickly and easily on any surface. -
Page 4: 3: Adding/Removing The Device
#3: Adding/removing the device #4: Physical installation Adding (Inclusion) - Z-Wave device learning mode, allowing to add Detection range: NOTE NOTE the device to existing Z-Wave network. Detection range of the Motion Sensor is shown below. Actual range Remember to add the Adding security To add the device to the Z-Wave network:... -
Page 5: 5: Operating The Device
#5: Operating the device Controlling the Motion Sensor with FIBARO Home Center controller: The Motion Sensor has a bulit-in motion detector, temperature sensor and light intensity sensor, which make it a multi-channel device. In the home Center interface it will be presented as three devices. -
Page 6: 6: Association
#6: Association #7: Z-Wave range test Association (linking devices) - direct control of other devices within The Motion Sensor has a built in Z-Wave network main controller’s NOTE CAUTION the Z-Wave system network e.g. Dimmer, Relay Switch, Roller Shutter range tester. Association allows di- or scene (may be controlled only through a Z-Wave controller). -
Page 7: 8: Advanced Parameters
The Motion Sensor allows to customize its operation to user’s needs. Available settings: 0 - 1 pulse The settings are available in the FIBARO interface as simple options that may be chosen by selecting the appropriate box. 1 - 2 pulses... - Page 8 9. Motion detection - night/day 20. Tamper - sensitivity This parameter defines the difference between night and day in terms This parameter determines the change in force acting on the device, of light intensity, used in parameter 8. that will result in reporting tamper alarm - g-force acceleration. Available settings: 1-32767 (1-32767 lux) Available settings: 0 - tamper inactive 200 (200 lux) Parameter size:...
- Page 9 This parameter provides backward compatibility with controllers not 66. Temperature offset supporting Z-Wave+. The value to be added to the actual temperature, measured by the sensor (temperature compensation). Available settings: 0 - backward compatible tamper alarm sent to 5th association group Available settings: -1000-1000 (-1000-1000°C, 1°C step) 1 - backward compatible tamper alarm sent in 0 (0°C)
-
Page 10: 9: Specifications
#9: Specifications 83. Visual LED indicator - illuminance for high indicator brightness Light intensity level above which brightness of visual indicator is set to 100%. Available settings: value of parameter 82 to 32767 (in lux) 1000 2 [bytes] Default setting: Parameter size: Power supply: 3.0v DC battery... -
Page 11: 10: Regulations
All information, including, but not limited to, information regarding the features, functionality, and/or other product specification are subject to change without notice. Fibaro reserves all rights to revise or upda- te its products, software, or documentation without any obligation to notify any individual or entity.
