OCS 100W Parts
32'
23'
Pull
23'
32'
Cover
Figure 6. OCS 100W Parts

Installation

ATTENTION:
Pull
• All structural steps and electrical installation must be performed by qualified personnel in accordance with local and
national building codes and electrical codes.
• Toute étape structurelle et installation électrique doit être effectuée par un personnel qualifié, conformément aux codes
de sécurité de bâtiments et de produits électriques en vigueur à l'échelle régionale et nationale.
• Only connect to Class III SELV systems.
• Connectez l'unité uniquement à des systèmes fonctionnant en très basse tension de sécurité (TBTS) de classe III.
1
Insert wiring through
Mounting Bracket.
"POP"
5
Snap sensor onto
mounting post.
Figure 7. OCS 100W Installation
40'
20'
Wiring
Harness
Sensory Coverage
Body
US Minor Motion
US Major Motion
Body
Cover
Building Wiring
Wall
6
Plug Wiring Harness into connector located
on the left side, opposite exit slot and place
wiring under wire tabs. Align sensor and tighten
position locking screw.
Mounting
Bracket
Bracket
Cover 40' - 0" Major Coverage
Mounting Bolt,
Washer and Nut. (2)
IR Minor Motion
IR Major Motion
Wiring
Harness
Bracket
Cover
4
Snap Bracket Cover in place to
conceal wiring and Mounting
Bracket.
Harness
Bracket
Cover
Loosen Tighten
Position
Locking
Screw
20' - 0" Minor Motion Coverage
Mounting
Bracket
Mounting Bolt,
Washer and nut. (2)
Wiring
2
Secure Mounting
Wall
Bracket to the wall.
3
Connect building wiring to
Wiring Harness with included
wire nuts.
Push
"SNAP"
7
Replace Cover.
10' - 0"
Mounting
Height
