This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children.
WARNING
Young children can be seriously injured or killed if furniture tips over. Don't use this
item for a TV stand or place heavy objects on top of item. Always use angle-braces or
anchors to secure furniture to the wall.
ASSEMBLY INSTRUCTIONS
RiverRidge® MEDFORD SPACESAVER
ITEM# 06-104 WHITE
ITEM# 06-105 ESPRESSO
ADULT ASSEMBLY REQUIRED
SEE FULL WARNING ON PAGE 2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for RiverRidge MEDFORD SPACESAVER 06-104
Summary of Contents for RiverRidge MEDFORD SPACESAVER 06-104
- Page 1 ASSEMBLY INSTRUCTIONS RiverRidge® MEDFORD SPACESAVER ITEM# 06-104 WHITE ITEM# 06-105 ESPRESSO ADULT ASSEMBLY REQUIRED This product requires assembly by an adult because of small parts. Care should be taken in unpacking and assembling this item to keep small parts away from children.
- Page 2 Send requests for missing or damaged parts by email to: customer.service@ssi-rr.com or call toll free 1-(844)-223-5201 or order parts on line at www.riverridgehome.com THIS SHELF UNIT WILL HOLD UP TO 25 POUNDS PER SHELF OR A TOTAL OF 75 POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 25 POUNDS OR 75 POUNDS TOTAL WEIGHT.
-
Page 3: Parts List
PARTS LIST DESCRIPTION TOP BOARD UPPER LEFT SIDE PANEL UPPER RIGHT SIDE PANEL ADJUSTABLE SHELF LEFT DOOR RIGHT DOOR BOTTOM SHELF MIDDLE BOARD LOWER LEFT SIDE PANEL LOWER RIGHT SIDE PANEL 3PCS CROSS BAR 2PCS UPPER BACK BOARD LOWER BACK BOARD PLASTIC CONNECTION STRIP... - Page 4 PARTS DESCRIPTION 12PCS CAM BOLT 12PCS CAM LOCK 8PCS WOOD DOWEL MAGNET 10PCS SCREW 3x14mm 2PCS METAL BRACKET 3PCS SCREW 3x10mm 4PCS SHELF HOLDER 5PCS SCREW 4x35mm 2PCS MAGNET PLATE 4PCS DOOR PIN 2PCS SCREW 4x25mm 2PCS KNOB 6PCS PLASTIC NUT 6PCS SCREW 5x35mm 6PCS...
- Page 5 STEP 1 STEP 1 1. Screw 4 cam bolts (A) into pre-threaded holes on top board (1). 2. Attach magnet (D) to top board (1) by inserting 2 screws (E) through holes on magnet (D) and tighten to top board (1). 3.
- Page 6 STEP 3 STEP 3 1. Attach magnet plate (J) to left door (5) by inserting 1 screw (G) through hole on magnet plate (J) and tighten to left door (5) 2. Attach knob (M) to left door (5) by inserting 1 screw (L) through hole on left door (5) and tighten to knob (M).
- Page 7 STEP 5 STEP 5 1. Slide lower back board (13) into grooves on upper left side panel (2), upper right side panel (3) and bottom shelf (7). 2. Insert 2 wood dowels (C) into dowel holes on upper left side panel (2) and upper right side panel (3). 3.
- Page 8 STEP 7 STEP 7 1. Insert 6 wood dowels (C) into wood dowel holes on end of cross bars (11). 2. Attach 3 cross bars (11) to lower left side panel (9) and lower right side panel (10) by inserting wood dowels (C) into wood dowel holes on lower left side panel (9) and lower right side panel (10).
- Page 9 STEP 9 STEP 9 1. Insert 4 shelf holders (H) into holes on upper left side panel (2) and upper right side panel (3) and make sure all 4 holders are on same level. STEP 10 STEP 10 1. Place adjustable shelf (4) onto shelf holders (H).
- Page 10 STEP 11 STEP 11 1. Attach 8 plastic brackets (S) to back of cabinet by inserting 8 screws (E) through holes on plastic brackets (S) and tighten to cabinet. STEP 12 STEP 12 1. Place drawing with hole position on wall in desired location and drill 1 hole through the hole position on the drawing.
