Summary of Contents for National Instruments 6711
- Page 1 (217) 352-9330 | Click HERE Find the National Instruments DAQCard-6715 at our website:...
- Page 2 6711/6713/6715 User Manual Analog Voltage Output Device for PCI/PXI/CompactPCI/PCMCIA/1394 Bus Computers 6711/6713/6715 User Manual December 1999 Edition Part Number 322080B-01 Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 3 For further support information, see the Technical Support Resources appendix. To comment on the documentation, send e-mail to techpubs@ni.com © Copyright 1998, 1999 National Instruments Corporation. All rights reserved. Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 4 Any action against National Instruments must be brought within one year after the cause of action accrues. National Instruments shall not be liable for any delay in performance due to causes beyond its reasonable control.
-
Page 5: Table Of Contents
About the 671X Devices ....................1-1 Using PXI with CompactPCI..................1-2 What You Need to Get Started ..................1-3 Unpacking ........................1-4 Software Programming Choices ..................1-4 National Instruments Application Software ............1-4 NI-DAQ Driver Software ................1-5 Register-Level Programming ................1-6 Optional Equipment .......................1-7 Custom Cabling ......................1-7... - Page 6 Calibration Loading Calibration Constants ..................5-1 Self-Calibration ......................5-2 External Calibration....................... 5-2 Other Considerations ..................... 5-3 Appendix A Specifications Appendix B Common Questions 6711/6713/6715 User Manual www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 7 PXI-6711/6713 J2 Pin Assignment ............1-3 Table 4-1. Signal Descriptions for I/O Connector Pins ..........4-4 Table 4-2. I/O Signal Summary for the 6711/6713 Device........4-6 © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 8: About This Manual
(DIO) channels for PXI/CompactPCI • PCI-6711 with four or PCI-6713 with eight AO channels, two counters, and eight DIO channels for PCI • DAQPad-6713 with eight AO channels, two counters, and eight DIO channels for IEEE-1394 (Firewire) •... -
Page 9: National Instruments Documentation
Refers to all PC AT series computers with PCI bus unless otherwise noted. SCXI SCXI stands for Signal Conditioning eXentsions for Instrumentation and is a National Instruments product line designed to perform front-end signal conditioning for National instruments plug-in DAQ devices. National Instruments Documentation... -
Page 10: Related Documentation
Related Documentation The following documents contain information you may find helpful: • DAQ-STC Technical Reference Manual • National Instruments Application Note 025, Field Wiring and Noise Considerations for Analog Signals • PCI Local Bus Specification Revision 2.0 • IEEE 1394-1995 specification ©... -
Page 11: Introduction
1 MS/s/channel for voltage outputs, eight lines of TTL-compatible digital I/O, and two 24-bit counter/timers for timing I/O. The 6711 device features four voltage output channels, while the 6713 and 6715 devices feature eight voltage output channels. Because the 671X device has no DIP switches, jumpers, or potentiometers, it is easily software-configured and calibrated. -
Page 12: Using Pxi With Compactpci
DAQ devices in your computer. If you are using the PXI-6711/6713 in a PXI chassis, RTSI lines, known as the PXI trigger bus, are part of the backplane, therefore you do not need the RTSI cable for system triggering and timing on the PXI. -
Page 13: What You Need To Get Started
Even if the sub-bus is capable of driving these lines, the 6711/6713 is still compatible as long as those pins on the sub-bus are disabled by default and are never enabled. Damage can result if these lines are driven by the sub-bus. -
Page 14: Unpacking
Never touch the exposed pins of connectors. Software Programming Choices You have several options to choose from when programming your National Instruments DAQ and SCXI hardware. You can use National Instruments application software, NI-DAQ, or register-level programming. National Instruments Application Software LabVIEW features interactive graphics, a state-of-the-art user interface, and a powerful graphical programming language. -
Page 15: Ni-Daq Driver Software
An example of a low-level function is writing directly to registers on the DAQ device. NI-DAQ does not sacrifice the performance of National Instruments DAQ devices because it lets multiple devices operate at their peak. -
Page 16: Register-Level Programming
Figure 1-1. The Relationship Between the Programming Environment, NI-DAQ, and Your Hardware Register-Level Programming The final option for programming any National Instruments DAQ hardware is to write register-level software. Writing register-level programming software can be very time-consuming and inefficient, and is not recommended for most users. -
Page 17: Optional Equipment
Chapter 1 Introduction Optional Equipment National Instruments offers a variety of products to use with the 671X device, including cables, connector blocks, and other accessories, as follows: • Cables and cable assemblies • Connector blocks, shielded and unshielded 50- and 68-pin screw terminals •... -
Page 18: Installation And Configuration
♦ PXI-6711/6713 You can install the PXI-6711/6713 in any available PXI slot in your PXI or CompactPCI chassis. © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... - Page 19 Remove the expansion slot cover on the back panel of the computer. Insert the 6711/6713 device into a 5 V PCI slot. Gently rock the device to ease it into place. It can be a tight fit, but do not force the device into place.
- Page 20 Chapter 2 Installation and Configuration The PCI-6711/6713 device is installed. You are now ready to configure your software. Refer to your software documentation for configuration instructions. ♦ DAQPad-6713 Connect the 1394 cable from the computer or any other 1394 device to the port on your DAQPad device.
-
Page 21: Device Configuration
Chapter 2 Installation and Configuration Device Configuration Due to the National Instruments standard architecture for data acquisition, the PCI bus specification, the IEEE-1394-1995 specification, the PCMCIA (PC Card) specification, and the 671X device is completely software configurable. There are two types of configuration on the 671X device—bus-related and data acquisition-related configuration. -
Page 22: Hardware Overview
Hardware Overview This chapter presents an overview of the hardware functions on your PCI/PXI-6711/6713 and DAQPad-6713 device. Figure 3-1 shows a block diagram of the 6711/6713 device. Figure 3-2 shows a block diagram of the 6715 device. © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... -
Page 23: Figure 3-1. 6711/6713 Block Diagram
Digital I/O (8) Digital I/O Timing/Control Interface +5 V RTSI Bus Note: CH4 through CH7 on 6713 only Figure 3-1. 6711/6713 Block Diagram 6711/6713/6715 User Manual www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 24: Figure 3-2. 6715 Block Diagram
RTSI Bus Timing Digital I/O Timing I/O Interface Digital I/O (8) +5 V 0.75 A Figure 3-2. 6715 Block Diagram © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 25: Analog Output
Chapter 3 Hardware Overview Analog Output The 6711 has four channels and the 6713/6715 has eight channels of voltage output at the I/O connector. The reference for the analog output circuitry is software selectable per channel. The reference can be either internal or external, whereas the range is always bipolar. -
Page 26: Timing Signal Routing
Timing Signal Routing The DAQ-STC provides a very flexible interface for connecting timing signals to other devices or external circuitry. The 6711/6713 device uses the RTSI bus to interconnect timing signals between devices (PCI/PXI/CompactPCI) and the Programmable Function Input (PFI) pins on the I/O connector to connect the device to external circuitry. -
Page 27: Programmable Function Inputs
DAC updates or general-purpose signals at the I/O connector. The 6711/6713 device can use either its internal 20 MHz timebase or a timebase received over the RTSI bus. In addition, if you configure the... -
Page 28: Rtsi Triggers
RTSI Triggers The seven RTSI trigger lines on the RTSI bus provide a very flexible interconnection scheme for the 6711/6713 device sharing the RTSI bus. These bidirectional lines can drive any of five timing signals onto the RTSI bus and can receive any of these timing signals. This signal connection scheme is shown in Figure 3-4. -
Page 29: Signal Connections
This chapter describes how to make input and output signal connections to your 671X device through the device I/O connector. ♦ PCI/PXI-6711/6713, DAQCard-6715 The I/O connector for the 6711/6713 device has 68 pins that you can connect to 68-pin accessories with the SH68-68-EP or similar 68-pin shielded cable. ♦... -
Page 30: Figure 4-1. 68-Pin I/O Connector Pin Assignment For The 671X Device
PFI9/GPCTR0_GATE PFI8/GPCTR0_SOURCE GPCTR0_OUT DGND FREQ_OUT DGND No Connect on PCI/PXI 6711 Figure 4-1. 68-Pin I/O Connector Pin Assignment for the 671 X Device 6711/6713/6715 User Manual www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 31: Figure 4-2. 50-Pin I/O Connector Pin Assignment For The 671X Device When Using The Sh68-50 Cable
PFI8/GPCTR0_SOURCE PFI9/GPCTR0_GATE 49 50 GPCTR0_OUT FREQ_OUT No Connect on PCI/PXI-6711 Figure 4-2. 50-Pin I/O Connector Pin Assignment for the 671 X Device When Using the SH68-50 Cable © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 32: I/O Connector Signal Descriptions
671X device can damage the 671X device and the computer. Maximum input ratings for each signal are given in the Protection column of Table 4-2. National Instruments is not liable for any damages resulting from such signal connections. - Page 33 The +5 V line on the connector of the DAQCard-6715 is fused at 0.75 A, however, the actual current available can be limited below this value by the host computer. National Instruments recommends limiting current from this line to 250 mA.
-
Page 34: Table 4-2. I/O Signal Summary For The 6711/6713 Device
Chapter 4 Signal Connections Table 4-2 shows the I/O signal summary for the 6711/6713 devices. Table 4-2. I/O Signal Summary for the 6711/6713 Device Rise Time Signal Impedance Protection Sink (ns)/ Type and Input/ (Volts) Source Slew Signal Name Direction... -
Page 35: Analog Output Signal Connections
The +5 V line on the connector of the DAQCard-6715 is fused at 0.75 A, however, the actual current available can be limited below this value by the host computer. National Instruments recommends limiting current from this line to 250 mA. - Page 36 The external reference signal can be either a DC or an AC signal. The device multiplies this reference signal by the DAC code, divided by the full-scale DAC code, to generate the output voltage. 6711/6713/6715 User Manual www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 37: Digital I/O Signal Connections
Caution Exceeding the maximum input voltage ratings, which are listed in Table 4-2, can damage the 671X device and the computer. National Instruments is not liable for any damages resulting from such signal connections. © National Instruments Corporation 6711/6713/6715 User Manual... -
Page 38: Figure 4-4. Digital I/O Connections
DIO6 and DIO7 to control the general-purpose counters. The up/down control signals are input only and do not affect the operation of the DIO lines. 6711/6713/6715 User Manual 4-10 www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 39: Power Connections
The +5 V line on the connector of the DAQCard-6715 is fused at 0.75 A, however, the actual current available can be limited below this value by the host computer. National Instruments recommends limiting current from this line to 250 mA. -
Page 40: Figure 4-5. Timing I/O Connections
PFI2 source to two 671X device PFI pins. PFI0 PFI2 PFI0 PFI2 Source Source DGND I/O Connector 6711/6713 Device Figure 4-5. Timing I/O Connections 6711/6713/6715 User Manual 4-12 www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 41: Programmable Function Input Connections
EXTSTROBE* Signal EXTSTROBE* is an output-only signal that is used for controlling SCXI devices. © National Instruments Corporation 4-13 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 42: Waveform Generation Timing Connections
Chapter 4 Signal Connections Waveform Generation Timing Connections The analog group defined for the 6711/6713 device is controlled by WFTRIG, UPDATE*, and UISOURCE. WFTRIG Signal Any PFI pin can externally input the WFTRIG signal, which is available as an output on the PFI6/WFTRIG pin. -
Page 43: Update* Signal
Figures 4-8 and 4-9 show the input and output timing requirements for the UPDATE* signal. Rising-edge polarity Falling-edge polarity = 10 ns minimum Figure 4-8. UPDATE* Input Signal Timing © National Instruments Corporation 4-15 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 44: Uisource Signal
Figure 4-10 shows the timing requirements for the UISOURCE signal. = 50 ns minimum = 10 ns minimum Figure 4-10. UISOURCE Signal Timing 6711/6713/6715 User Manual 4-16 www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 45: General-Purpose Timing Signal Connections
Figure 4-11 shows the timing requirements for the GPCTR0_SOURCE signal. = 50 ns minimum = 10 ns minimum Figure 4-11. GPCTR0_SOURCE Signal Timing © National Instruments Corporation 4-17 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 46: Figure 4-12. Gpctr0_Gate Signal Timing In Edge-Detection Mode
TC and toggle output polarity on TC. The output polarity is software selectable for both options. This output is set to tri-state at startup. Figure 4-13 shows the timing of the GPCTR0_OUT signal. 6711/6713/6715 User Manual 4-18 www.ni.com... -
Page 47: Gpctr1_Source Signal
As an output, the GPCTR1_SOURCE monitors the actual clock connected to general-purpose counter 1. This is true even if the source clock is externally generated by another PFI. This output is set to tri-state at startup. © National Instruments Corporation 4-19 6711/6713/6715 User Manual... -
Page 48: Gpctr1_Gate Signal
As an output, the GPCTR1_GATE signal monitors the actual gate signal connected to general-purpose counter 1. This is true even if the gate is externally generated by another PFI. This output is set to tri-state at startup. 6711/6713/6715 User Manual 4-20 www.ni.com... -
Page 49: Figure 4-15. Gpctr1_Gate Signal Timing In Edge-Detection Mode
GPCTR1_OUT signal. GPCTR1_SOURCE GPCTR1_OUT (Pulse on TC) GPCTR1_OUT (Toggle output on TC) Figure 4-16. GPCTR1_OUT Signal Timing © National Instruments Corporation 4-21 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 50: Gpctr1_Up_Down Signal
The GATE input timing parameters are referenced to the signal at the SOURCE input or to one of the internally generated signals on the 6711/6713 device. Figure 4-17 shows the GATE signal referenced to the rising edge of a source signal. The gate must be valid (either high or low) -
Page 51: Freq_Out Signal
For more information, refer to the application note, Field Wiring and Noise Consideration for Analog Signals, available from National Instruments. © National Instruments Corporation 4-23 6711/6713/6715 User Manual... -
Page 52: Calibration
This means that you can load the CalDACs with values either from the original factory calibration or from a calibration that you subsequently performed. © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... -
Page 53: Self-Calibration
The 671X device can measure and correct for almost all of its calibration-related errors without any external signal connections. Your National Instruments software provides a self-calibration method. This self-calibration process, which generally takes less than two minutes, is the preferred method of assuring accuracy in your application. Initiate self-calibration to minimize the effects of any offset, gain, and linearity drifts, particularly those due to warmup. -
Page 54: Other Considerations
For example, to calibrate a 12-bit device, the external reference should be at least ±0.0062% (±62 ppm) accurate. Note National Instruments recommends using a +5 V external reference voltage when performing calibration. Other Considerations The CalDACs adjust the gain error of each analog output channel by adjusting the value of the reference voltage supplied to that channel. -
Page 55: Appendix A Specifications
Number of channels ....... 8 voltage outputs (6713/6715 devices) 4 voltage outputs (6711 devices) Resolution ..........12 bits, 1 in 4,096 © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... - Page 56 Max update rate in FIFO mode will not change irrespective of the number of devices in the system. These results were measured using one PCI-6711/6713 device with a 90 MHz Pentium machine. These numbers may change when using more devices or when other CPU or bus activity is taking place.
- Page 57 Before calibration ......±0.5% of output max Gain error (relative to external reference) ....+0% to +0.5% of output max, not adjustable © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 58 ±15 V powered off Input impedance ........10 kΩ Bandwidth (-3 dB) ........1 MHz Dynamic Characteristics Slew rate ..........20 V/µs Noise 6711/6713 ........200 µV , DC to 1 MHz DAQCard-6715 .......400 µV , DC to 1 MHz 6711/6713/6715 User Manual www.ni.com...
- Page 59 Appendix A Specifications Channel crosstalk 6711/6713 ........– 70 dB with SH6868EP cable (generating a 10 V, 10 pt sinusoidal at 100 KHz on the reference channel) DAQCard-6715....... – 60 dB (generating a 10 V, 10 pt sinusoidal at 100 KHz on the reference channel) Total harmonic distortion.......
- Page 60 Base clock accuracy........±0.01% over operating temperature Max source frequency......20 MHz Min source pulse duration .....10 ns, edge-detect mode Min gate pulse duration ......10 ns, edge-detect mode 6711/6713/6715 User Manual www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 61 Appendix A Specifications Data transfers ......... DMA (6711/6713 only), interrupts, programmed I/O DMA modes........... Scatter-gather (6711/6713 only) Triggers Digital Trigger Compatibility ......... TTL Response ..........Rising or falling edge Pulse width..........10 ns min RTSI and PXI Trigger Lines ♦...
- Page 62 I/O connector Physical Dimensions (not including connectors) PCI-6711/6713 ........17.5 by 10.7 cm (6.87 by 4.2 in.) PXI-6711/6713 ........16 by 10 cm (6.3 by 3.9 in.) DAQPad-6713 .........30.5 by 24.4 by 4.45 cm (12 by 10 by 1.75 in.) DAQCard-6715 .......Type II PC Card...
- Page 63 It means that this is the fastest you can output data from your device and still achieve accurate results. The 6711/6713 device has an update rate of 1 MS/s at up to 4 channels, and the DAQCard-6715 device has an update rate of 1 MS/s on 1 channel and 480 kS/s on all eight channels simultaneously.
- Page 64 Common Questions What type of 5 V protection does the 671X device have? The 6711/6713 device has 5 V lines equipped with a self-resetting 1 A fuse. The 6715 device has 5 V lines equipped with a self-resetting 0.75 A fuse.
- Page 65 This pull-up resistor will set the DIO(0) pin to a logic high when the output is in a high impedance state. © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 66 Technical Support Resources This appendix describes the comprehensive resources available to you in the Technical Support section of the National Instruments Web site and provides technical support telephone numbers for you to use if you have trouble connecting to our Web site or if you do not have internet access.
- Page 67 If you have trouble connecting to our Web site, please contact your local National Instruments office or the source from which you purchased your National Instruments product(s) to obtain support. For telephone support in the United States, dial 512 795 8248. For...
- Page 68 ± plus or minus positive of, or plus – negative of, or minus Ω ohms © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 69 Analog signals can be single-ended or differential. For digital signals, you group channels to form ports. Ports usually consist of either four or eight digital channels. centimeter 6711/6713/6715 User Manual www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 70 Data acquisition system timing controller. An application-specific integrated circuit (ASIC) for the system timing requirements of a general A/D and D/A system, such as a system containing the National Instruments E Series devices. decibel—the unit for expressing a logarithmic measure of the ratio of two...
- Page 71 DAQ device. FREQ_OUT frequency output signal feet GATE gate signal GPCTR general-purpose counter signal 6711/6713/6715 User Manual www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 72 © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 73 NI-DAQ National Instruments driver software for DAQ hardware noise an undesirable electrical signal—Noise comes from external sources such as the AC power line, motors, generators, transformers, fluorescent lights, CRT displays, computers, electrical storms, welders, radio transmitters, and internal sources such as semiconductors, resistors, and capacitors.
- Page 74 (2) a digital port, consisting of four or eight lines of digital input and/or output parts per million pull-up random access memory root mean square © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 75 RTSIbus Real-Time System Integration bus—the National Instruments timing bus that connects DAQ devices directly, by means of connectors on top of the devices, for precise timing synchronization between multiple devices RTSI_OSC RTSI Oscillator—RTSI bus master clock...
- Page 76 (for example, 0 to +10 V) UPDATE update signal volts volts direct current © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 77 WFTRIG waveform generation trigger signal 6711/6713/6715 User Manual G-10 www.ni.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 78 4-7 to 4-9 +5 V signal description (table), 4-4 description (table), 4-4 signal summary (table), 4-6 power connections, 4-11 self-resetting fuse, 4-11, B-2 6711/6713/6715 devices. See also hardware overview. block diagrams custom cabling, 1-7 6711/6713, 3-2 optional equipment, 1-7 6715, 3-3...
- Page 79 (table), 4-6 GPCTR0_UP_DOWN signal, 4-19 documentation GPCTR1_GATE signal, 4-20 to 4-21 conventions used in manual, ix-x GPCTR1_OUT signal, 4-21 National Instruments documentation, x-xi GPCTR1_SOURCE signal, 4-19 to 4-20 related documentation, xi GPCTR1_UP_DOWN signal, 4-22 to 4-23 questions about, B-3...
- Page 80 MITE bus interface chip, 1-1 reglitch selection, 3-4 block diagrams 6711/6713, 3-2 6715, 3-3 National Instruments Web support, C-1 to C-2 digital I/O, 3-4 NI-DAQ driver software, 1-5 to 1-6 timing signal routing, 3-5 to 3-7 device and RTSI clocks, 3-6...
- Page 81 671X device with SH68-50 cable 4-7 to 4-9 (figure), 4-3 digital I/O, 4-9 to 4-10 J2 pin assignments for PXI-6711/6713 field wiring considerations, 4-23 (table), 1-3 general-purpose timing signal power connections, 4-11 connections, 4-17 to 4-23...
- Page 82 A-3 timing I/O, A-6 to A-7 triggers stability specifications, A-5 digital trigger specifications, A-7 questions about, B-2 to B-3 © National Instruments Corporation 6711/6713/6715 User Manual Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 83 4-14 to 4-17 UISOURCE signal, 4-16 to 4-17 UPDATE* signal, 4-15 to 4-16 WFTRIG signal, 4-14 to 4-15 Web support from National Instruments, C-1 to C-2 online problem-solving and diagnostic resources, C-1 software-related resources, C-2 WFTRIG signal...
