- Page 1 SKF THHP 300 Instructions for use...
-
Page 2: Table Of Contents
Table of contents Safety precautions .......................... 3 EU Declaration of Conformity ......................3 1. Application ..........................4 2. Description ..........................4 General description ............................4 Technical data ...............................4 Contents list ..............................5 Suggested connections ..........................6 Spare parts and optional accessories ......................6 Application connection nipples ........................7 Hydraulic oil ..............................7 3. -
Page 3: Safety Precautions
EU Declaration of Conformity equipment operation. In case of any uncertainties as THHP 300 regards the use of the equipment contact SKF. Failure to comply with the following could cause We, SKF MPT, Meidoornkade 14, 3992 AE Houten, equipment damage and personal injury. -
Page 4: Application
1. Application 2. Description The SKF High Pressure Pump, THHP 300, is 2.1 General description intended for the mounting and dismounting of pressure joints using the SKF Oil Injection Method. The SKF High Pressure Pump THHP 300 consists This includes such applications as couplings, gears, of a high-pressure pump with a 0-300MPa pulleys, flywheels and SKF OK Couplings;... -
Page 5: Contents List
Contents list The THHP 300 is supplied complete with the following accessories: Fig.1 – SKF THHP 300 Content Item Description Pump body High pressure hose (assembled) Pressure gauge and protection sleeve (assembled) Quick connection coupling (assembled) Connection nipple M16male - G1/4male... -
Page 6: Suggested Connections
Parts Assembly of hydraulic pump body and pressure gauge THHP 300-1 A, C High pressure hose 2 m long THHP 300-2H (M16x1.5m – G1/4f) Pressure gauge (0-300 MPa/ 43500psi) 1077589 Pressure gauge protection sleeve TMJG 100S Connection nipple M16m - G1/4m... -
Page 7: Application Connection Nipples
LHMF 300. Dirt and metal particles in the oil can cause wear of the piston mating surfaces, leading to excessive oil leakage and permanent damage to the THHP 300. The recommended oil cleanliness level should meet or exceed ISO 4406:1999 20/18/15. -
Page 8: Preventive Maintenance
If any products are found to be damaged or defective, mark them clearly and store them in a specially designated area for unsuitable material. Consider using the SKF repair service to get it back in good working order. 4. Assembly and operating instructions The pump has a stop lever clip to lock the handle. -
Page 9: Prepare The Application
4.3 Prepare the application Screw the appropriate THPN nipple, with G thread, to the application. Screw on the loose quick connection nipple (THPN 300-1) to the THPN nipple: Maximum torque for M16 thread is 40-50 Nm / 29.5-36.9 ft-lb († fig. 2). For dismounting of components make sure that with the built up of oil pressure these are not suddenly released and can’t freely fly away from... -
Page 10: Problem Solving
5. Problem solving The pump does not supply oil: • Pump relief valve open • Badly connected couplings • Shortage of oil in tank • Accumulation of dirt in the circuit The pump does not reach maximum pressure: • Safety valve on wrong setting •... -
Page 11: Detailed Dimensions
6. Detailed dimensions Here below a drawing of the main dimensions of the pump. 200 mm (7.9 in.) 574 mm (22.6 in.) 436 mm (17.2 in.) 102 mm 130 mm (4.0 in.) (5.1 in.) 4 x 13 mm (0.5 in.) Fig.8 –... - Page 12 | mapro.skf.com | skf.com/mount ® SKF is a registered trademark of the SKF Group. © SKF Group 2020 The contents of this publication are the copyright of the publisher and may not be reproduced (even extracts) unless prior written permission is granted. Every care has been taken to ensure the accuracy of the information contained in this publication but no liability can be accepted for any loss or damage whether direct, indirect or consequential arising out of the use of the information contained herein.
