OptimAir
INSTRUCTIONS
Powered Air-Purifying Respirator
THIS MANUAL, INCLUDING THE WARNINGS AND CAUTIONS INSIDE,
MUST BE READ AND FOLLOWED CAREFULLY BY ALL PERSONS WHO
HAVE OR WILL HAVE THE RESPONSIBILITY FOR USING OR SERVICING THE
PRODUCT. These respirators will perform as designed only if they are
used and serviced according to the instructions. OTHERWISE, THEY
COULD FAIL TO PERFORM AS DESIGNED, AND PERSONS WHO RELY ON
THESE RESPIRATORS COULD SUSTAIN SERIOUS PERSONAL INJURY OR
DEATH.
The warranties made by MSA with respect to the product are voided if
the product is not used and serviced according to the instructions in this
manual. For any additional information relative to use or repair, write or
call 1-800-MSA-2222 during regular working hours.
See separate insert for NIOSH approval information (P/N 816882).
For More Information, call 1-800-MSA-2222 or Visit Our Website at www.MSAnet.com
The Safety Company
TAL 804 (L) Rev. 17
®
WARNING
© MSA 2008
6A
Prnt. Spec. 10000005389(A)
Mat. 490883
Doc. 490883
