Introduction
1.2 Description
•
•
1.2
Description
The RUGGEDCOM MX5000 features various ports, controls and indicator LEDs
on individual modules and the front panel for connecting, configuring and
troubleshooting the device.
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
10
11
12
Figure 1.1
When the RUGGEDCOM MX5000 is configured for rack front mounting, these ports,
controls and LEDs are located on the front panel.
2
Terminal blocks for reliable maintenance-free connections
CSA/UL 62368-1 safety approved to 85 °C (185 °F)
1
11
10
12
Control Module
Power Supply Module
Line Module (Typical)
Alarm Indicator LED
Lamp Test/Alarm Cut-Off (LT/ACO) Button
Management Ethernet Port
Utility USB Port
RS232 Serial Console Port (DB9)
Failsafe Alarm Relay
CompactFlash Card Port
Power Supply Module Indicator LEDs
Power Supply Terminal Block
RUGGEDCOM MX5000 Modules
2
3
4
RUGGEDCOM MX5000
Installation Manual, 01/2021, C79000-G8976-1059-13
