Operation
SR7 Airless Sprayer
- For portable spray applications of architectural paints and coatings -
IMPORTANT SAFETY INSTRUCTIONS.
Read all warnings and instructions in this
manual. Save these instructions.
Model: 261810, Series A
Maximum Working Pressure: 3000 psi (21 MPa, 207 bar)
Dispense Rate: 0.31 gpm (1.17 lpm)
Includes:
Gun: SG10
Hose: 1/4 inch x 35-ft. (6.4 mm x 11 m)
Specifications
This equipment is not intended for use with flammable or
combustible materials used in places such as cabinet shops
or other "factory" or fixed locations. If you intend to use this
equipment in this type of application, you must comply with
NFPA33 and OSHA requirements for the use of flammable
and combustible materials.
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2007, Graco Inc. is registered to I.S. EN ISO 9001
The manual provided with this
sprayer contains
English, Español and Français.
Visit our website;
http://M
ti9193a
.Graco.com
AGNUM
311984A
ti9338a
ti9208a
