AIRCRAFT SPECIFICATIONS:
Wing Span: 2160.5mm/80.06"
Wing Area: 61.21 Sq dm/ 948.73 Sq in
Lenght:1490.2mm/58.67in
Weight: 3600g
RECOMMENDED EQUIPMENT：
Engine: 26--35CC gas engine
Radio: 4 channels, 6 servos
Warning! This model is not a toy.
It is designed for maximum performance. Please seek
advice if one is not familiar with this kind of electric
powered precision model.
Operating this model without prior preparation may cause
in juries.
Remember, safety is the most important thing. Always keep
this instruction manual at hand for quick reference.
Advertisement
Related Manuals for HobbyKing Stinson Reliant
Summary of Contents for HobbyKing Stinson Reliant
- Page 1 AIRCRAFT SPECIFICATIONS: Wing Span: 2160.5mm/80.06" Wing Area: 61.21 Sq dm/ 948.73 Sq in Lenght:1490.2mm/58.67in Weight: 3600g RECOMMENDED EQUIPMENT： Engine: 26--35CC gas engine Radio: 4 channels, 6 servos Warning! This model is not a toy. It is designed for maximum performance. Please seek advice if one is not familiar with this kind of electric powered precision model.
- Page 2 1. Wing Wings Part List Fix the hinge with instant glue Fix the aileron’s servo Cut the covering away for installing the aileron servo Fix the aileron horn Completed aileron servo system’s installing...
- Page 3 2.Main Landing Wheel passes the wheel shaft and M4 Wheelchocks Main Landing Wheel Part List through wheel Fix the main landing chassis Put the complete wheel parts into the wheel locking cowling then the M4 Wheelchocks Fix the main landing chassis’s Cut the covering away decorative cover...
- Page 4 3.Stabilizer/Vertical/Tail Wheel Cut the covering away for install Stabilizer Part List the elevator’s servo and horizontal tail Put the barrel bolt through the Must be installing the elevator’s servos fuselage first Fix the horizontal tail Fix the hinge with instant glue...
- Page 5 Completed the elevator servo system installing Install the tail wheel and cut the Vertical/Tail Wheel Part List redundant steel wire Fix the tail wheel set Fix the rudder hinge with instant gle...
- Page 6 Fix the tail wheel set and rudder linkage Fix the rudder’s servo controls Fix the rudder horn Judging by the picture passes through the steel wire and clamp the aluminium tube for fixing the steel wire...
- Page 7 Completed the rudder servo system installing 4.Wing Support Fix the wing with 2pcs M4*25 hand Scuff the aluminium sheet with sand screw paper to ensure a good glue bond Fix the aluinium sheet with epoxy glue Fix the wing support with 4pcs M3 cross head screws...
- Page 8 5.Canopy/Cowling/Engine/Fuel Tank Engine Mounting/Fuel Tank Part List Canopy/Cowlling Part List Draw a mark for drilling the hole to Judging by the mark to drilling the hole fix 2pcs nuts with claws Pressed-into 2pcs M3 nuts with claws Fix the fuel tank...
- Page 9 Fix the Canopy Fix the plywood with epoxy glue Fix the engine support with 4pcs Install the engine and the Throttle Pushwire M4*30 socket head screw Draw a mark for drilling the hole to Judging by the mark to drilling the hole fix the cowling...
- Page 10 Fix the cowling 6.Canopy/Cowling/Engine/Fuel Tank Side Window Part List Fix the PVC with instant glue Fix the PVC with instant glue Fix the side windows...
