ORION TELESCOPES & BINOCULARS Dob Dolly Instruction Manual

Orion Dob Dolly
#10109
Congratulations on the purchase of the Orion Dob Dolly.
This product was designed so that any Classic, Intelli­
Scope or Goto, Dobsonian telescope ranging from 4.5"
to 10" aperture can be easily moved around and lev­
eled adding more mobility to the Dobsonian telescope.
For Goto Dobs, leveling the base makes the Goto more accurate.
Getting Started
The Dob Dolly is supplied disassembled. Minor assembly is
required.
Providing Exceptional Consumer Optical Products Since 1975
inStructiOn MAnuAl
Figure 1. Dob Dolly parts
Dob Dolly parts
1. 3x Levelers
2. 12x Caster Wheel fixing screws
3. Directional Caster Wheel
4. Non­Directional Caster Wheel
5. Flat triangle surface
Assembling the Dob Dolly
Start by installing the two Non­Directional caster wheels
(Figure 2.). The two Non­Directional caster wheels are located
on the back of the Dob Dolly as shown (Figure 3.) The Dob­
Dolly has pre drilled holes to help positioning and fixing the
caster wheels.
Figure 2. Installing the caster wheels and levelers.
