Getting Started

Configure SoundGrid and assign your devices as follows, however large or small your system.

Connect the hardware

Install the software
Configure your system
Connect the Hardware

One I/O

In this example, one DiGiGrid D is used to connect a console to the SoundGrid host application's SoundGrid ASIO/Core
Audio driver for plugin processing and/or DAW playback/recording. The interface is connected directly to the host using a
Cat 5e Ethernet cable or better.
The LAN port that's connected to the SoundGrid network should be used for SoundGrid only. Do not share this port with
the internet or other networks.
In this configuration, all plugin processing is carried out on the host computer. The speed and power of the host defines
overall latnecy.
5
SoundGrid host computer
SoundGrid I/O device
