- Page 1 HEROSE GMBH ARMATUREN UND METALLE Operating instructions Diverter valve 0651X/0652X/0653X...
- Page 3 Operating instructions IMPORTANT Read carefully before use. Keep for future reference. © 2020 HEROSE GMBH ARMATUREN UND METALLE Elly-Heuss-Knapp-Straße 12 23843 Bad Oldesloe Germany Phone: +49 4531 509 – 0 +49 4531 509 – 120 Fax: E-mail: info@herose.com Web: www.herose.com...
-
Page 4: Table Of Contents
Operating instructions Table of contents About these instructions.....................1 Safety ..........................1 Transport and storage......................4 Description of the diverter valve ..................4 Assembly ..........................7 Operation..........................9 Maintenance and service ....................10 Disassembly and disposal ....................12 Phone +49 4531 509-0... -
Page 5: About These Instructions
They understand the operating principles of the diverter valve within the scope of their work and are able to recognise and av oid the hazards of the work. They hav e understood the operating instructions and are able to implement the information of the operating instructions accordingly. herose.com... - Page 6 Operating instructions Personal protective equipment Missing or unsuitable personal protective equipment increases the risk of damage to health and injuries to people. The f ollowing protectiv e equipment is to be prov ided and worn during work: Protectiv e clothing ...
- Page 7 Depressurise and empty all supply lines before dismounting the safety valve. Make sure that the sy stem is depressurised. Secure against being pressurised again. Do not bend ov er the saf ety valve when dismounting. herose.com...
-
Page 8: Transport And Storage
The div erter v alves are prov ided with an indiv idual marking for identification. Symbol Explanation Nominal diameter Nominal pressure (max. permissible operating pressure) -…..°C+…..°C Temperature, min. / max. Manuf acturer's mark "HEROSE" 01/16 Date of manuf acture, MM/Y Y 12345 Ty pe 01234567 Serial no. - Page 9 -196 °C to +120 °C 50 bar 06531 Media Gases, cry ogenic liquefied gases and their gas mixtures, such as: Name Argon Chlorotrif luoromethane Nitrous oxide Ethane Ethy lene Carbon dioxide Carbon monoxide Kry pton Methane Oxy gen Nitrogen Trif luoromethane herose.com...
- Page 10 See catalogue page. Lifetime The user is obligated to use Herose products only for their intended purpose. In this case, a technical service life may be assumed in accordance with the underly ing product standards (e.g. EN1626 f or shut-off valves and EN ISO 4126-1 f or safety valves).
-
Page 11: Assembly
Temperature-dependent changes in length in the pipework sy stem must be compensated with expansion joints. Fasten the div erter valve with the existing threads in the body. The div erter v alve must be protected against dirt and damage during construction work. Check the leak-tightness. herose.com... - Page 12 Operating instructions Tightening torques Number of Tightening torques (Nm) layers of PTFE tape 06510 / 06511 / 06512 / 06513 1.1/4 1.1/2 06520/ 06530 06521/ 06531 Plug screw Test thread Phone +49 4531 509-0...
-
Page 13: Operation
Dirt and residues hav e been remov ed from the pipeline and div erter valve in order to prev ent leaks. Lever position Outlet Outlet Inlet Standard position Lev er position lef t Outlet closed Inlet Lev er position right Outlet closed Inlet herose.com... -
Page 14: Maintenance And Service
Operating instructions Maintenance and service Safety during cleaning Take note of the specifications in the safety data sheet and the general occupational health and saf ety rules if degreasers are used for process-related reasons for the cleaning of bearing parts, f ittings and other precision parts. - Page 15 Returns / complaints Use the Serv ice f orm in case of returns/complaints. Contact in case of service: Herose.com › Serv ice › Product service › Complaints E-mail: serv ice@herose.com Fax: +49 4531 509 – 9285 herose.com...
-
Page 16: Disassembly And Disposal
Operating instructions Disassembly and disposal Notes regarding the disassembly Take note of all national and local saf ety requirements. The pipework sy stem must be depressurised. The medium and the div erter v alve must be at ambient temperature. ...
