Tosibox Lock 200 Quick Start Manual

1

Serializing the Lock and Key

TOSIBOX Lock
®
AC Adapter
Power 8-30V DC
1.
2.
3.

Deploying into Broadband Networks

2a
3G/4G, DSL
x
Firewall & NAT Friendly
Remote user
Lock 200
Quick Start Guide v1.4
Copyright © Tosibox Oy, 2015
Connect the AC adapter to the Lock and wait for 2 minutes.
Serialize the Key to the Lock by inserting the Key into the USB port of the
Lock. When the LED on the Key turns off or the Info LED in Lock front panel
stops blinking, the serialization is complete. This procedure takes approx.
10 seconds.
Go to 2a if deploying into broadband networks or
mobile networks. If deploying Locks as DHCP client into existing networks,
please see the TOSIBOX user manual.
®
3G/4G, DSL
x
Firewall & NAT Friendly
WAN
Internet /xDSL router
2b
TOSIBOX Lock
®
1. Connect an internet-connected ethernet cable
to the Lock's WAN port
2. Plug the devices into the Lock's LAN ports (LAN
1-3). If the devices have static IP addresses,
Deploying the Lock
manual.
TOSIBOX ® Key
if deploying into
.
in the TOSIBOX ® user
