I-jet
Pin Name
direction
TDI Output Test Data
Input
TDO Input Test Data
Output
RTCK Input TCK
Return
PD Input Power
Detect
EMU0 I/O Emulation 0 Depending on the device, EMU pins support boot
EMU1 I/O Emulation 1 Depending on the device, EMU pins support boot
nRESET I/O System
Reset
Table 8: cTI20 pin definitions
Description
IEEE 1149.1 scan data input to the device.
IEEE 1149.1 scan data output from the device.
Used only in Adaptive Clocking mode. I-jet monitors
RTCK to determine when to send the next TCK.
Should be tied to the I/O voltage of the target device.
Used by I-jet to detect if target power is active and to
set the JTAG signal voltage reference for level
translators.
modes and other features. I-jet does not use this pin but
it is routed to the TRACEDATA[2] pin on the MIPI20
connector. For proper booting, this pin should be
pulled-up on the target.
modes and other features. I-jet does not use this pin but
it is routed to the TRACEDATA[3] pin on the MIPI20
connector. For proper booting, this pin should be
pulled-up on the target.
Active LOW open-collector signal that can be driven by
I-jet to reset the device and/or the target board.
I-jet senses this line to determine when a board has
been reset by the user or by watchdog timer.
